Rocker Guards Sprinter 4wd 170 Inch Wheelbase Only Fits Non-Lifted Sprinter 2500/3500/3500XD (2015-2022) - Van Compass - 4090

More than just a step! Add functional protection, chassis rigidity and ease of access to your 170 Inch wheelbase 4X4 Sprinter in sleek style with a set of Van Compass Rocker Guards.

Our signature stealth design cues create an attractive 4 Inch wide step to make getting in and out of your van more convenient, and the rear portion features an additional 1 Inch of width for additional protection on tight trails. This robust design offers excellent body protection and adds easy to access vehicle lifting points.

Integrated Hi-Lift jack slots make off-road recovery or flat tire changes go quickly and safely.

The main step surfaces are constructed from 1/8 Inch steel and attach to the pinch seam with stainless steel hardware. Frame mounts are constructed from 3/16 Inch steel and are attached in three locations directly to the vehicle's chassis.

This additional reinforcement not only ensures a safe and solid mounting location, but increases torsional rigidity in the chassis of the vehicle. Drilling of holes at the pinch seam and under body gussets are required for installation.

Features and Benefits:


Frame mounts are constructed from 3/16 Inch steel and are attached in three locations directly to the vehicle's chassis

Drilling of holes at the pinch seam and under body gussets are required for installation

Please specify your van's lift height when ordering, the front subframe tie ins are specific to lifted and non-lifted vans

The main step surfaces are constructed from 1/8 Inch steel and attach to the pinch seam with stainless steel hardware

Integrated Hi-Lift jack slots make off-road recovery or flat tire changes go quickly and safely

More than just a step! Add functional protection, chassis rigidity and ease of access to your 170 Inch wheelbase 4X4 Sprinter in sleek style with a set of Van Compass Rocker Guards

This additional reinforcement not only ensures a safe and solid mounting location, but increases torsional rigidity in the chassis of the vehicle

Our signature stealth design cues create an attractive 4 Inch wide step to make getting in and out of your van more convenient, and the rear portion features an additional 1 Inch of width for additional protection on tight trails

Not Compatible with Winnebago Boldt, water tanks are in the way These ship in a very long crate, non-commercial address may be subject to additional delivery fees

Step Surface Width: 3

5-4 Inch (van body has slight taper at front door sill); 4

This robust design offers excellent body protection and adds easy to access vehicle lifting points

375 Inch at rear kick out with doors closed

Vans with a 2 Inch Van Compass lift require a unique mount, all other known variations use the 'non-lifted' version


Associated Comments:


Note: Please specify your van's lift height when ordering, the front subframe tie ins are specific to lifted and non-lifted vans. Vans with a 2 Inch Van Compass lift require a unique mount, all other known variations use the 'non-lifted' version.

Note: Not compatible with Winnebago Boldt, water tanks are in the way

Step Surface Width: 3.5-4 Inch (van body has slight taper at front door sill); 4.375 Inch at rear kick out with doors closed.


Van Compass Rocker Guards - Sprinter 4WD,170 Inch Wheelbase, Only Fits Non-Lifted

Details:


Recommended Shop Labor Time: 6 Hours

Color: Black

Material: Steel

Drilling Required: Yes

Attachment Type: Bolt On

Configuration: One Piece

Cutting Required: No

Paintable: Yes

Removable: Yes

Step Depth: 4 Inch

Drive: 4WD

Warranty: 60 Days-Finish Limited Lifetime-Structural


These ship in a very long crate, non-commercial address may be subject to additional delivery fees.
