Performance Aluminum Radiator, fits Toyota Tacoma 2024+ - Mishimoto - MMRAD-TAC-24

Keep your 2024+ Toyota Tacoma cool and dependable on every drive with a radiator built for strength and endurance. The Mishimoto Performance Aluminum Radiator replaces the stock plastic unit with a fully TIG-welded aluminum design that eliminates weak points and provides reliable performance under tough conditions. A uniquely engineered mounting bracket system proven through internal vibration testing delivers exceptional resistance to chassis flex and off-road abuse. -- Internal strutted tubes strengthen the core to prevent fatigue over time while a 46% increase in core volume and 23% greater fluid capacity improve heat dissipation and overall cooling efficiency. The built-in 7-row stacked plate transmission cooler outperforms the stock tube-style design providing superior control of transmission temperatures when towing off-roading or running heavier aftermarket parts. -- Every detail is crafted for long-term reliability. The increased coolant capacity improves thermal stability while the magnetic drain plug captures debris to help protect the cooling system. Whether you're heading into the mountains or navigating daily traffic this radiator ensures consistent performance and lasting durability all backed by the Mishimoto Lifetime Warranty.
All-aluminum construction with TIG-welded end tanks for maximum strength and leak-free reliability
46% increase in core volume and 23% greater fluid capacity for superior heat management
Upgraded mounting bracket system tested for resistance to vibration
Drain Plug Thread Size: M12 - 1.5
Core Finish: Uncoated
Drain Plug Included: Yes
Overall Height: 28.9 IN
Core Height: 27.8 IN
Core Thickness: 1.6 IN
Core Material: Aluminum
Outlet Location: Right
Transmission Oil Cooler Included: Yes
Transmission Oil Cooler Fitting Type: N/A
Radiator Cap Included: No
Core Length: 24.4 IN
Core Row Quantity: 7
Inlet Diameter: 1.3 IN
Inlet Location: Top Left
Outlet Diameter: 1.3 IN
Fluid Capacity: 0 GA
Down Flow Or Cross Flow Type: Cross Flow
Overall Length: 31.6 IN
Overall Width: 5.4 IN
Install Difficulty: 3
Prop 65 - Short Label: WARNING: Cancer and Reproductive Harm - www.p65warnings.ca.gov
Prop 65 Y/N: Y
SellingPoint01: All-aluminum construction with TIG-welded end tanks for maximum strength and leak-free reliability
SellingPoint02: 46% increase in core volume and 23% greater fluid capacity for superior heat management
SellingPoint03: Upgraded mounting bracket system tested for resistance to vibration
SellingPoint04: Internal strutted tubes strengthen the core to resist chassis flex when towing and off-roading
SellingPoint05: 7-row stacked plate in-tank transmission cooler provides improved cooling capabilities over stock
SellingPoint06: Included magnetic drain plug helps capture debris to extend the life of the cooling system
SellingPoint07: Designed to support the added demands of larger tires lifts and extra accessories
SellingPoint08: Mishimoto Lifetime Warranty
SellingPoint09: N/A
SellingPoint10: N/A
SellingPoint11: N/A
SellingPoint12: N/A
SellingPoint13: N/A
SellingPoint14: N/A
SellingPoint15: N/A
TechSpec Applications: Toyota Tacoma Limited 2.4 L4 2024-2025--Toyota Tacoma SR 2.4 L4 2024-2025--Toyota Tacoma SR5 2.4 L4 2024-2025--Toyota Tacoma TRD Off-Road 2.4 L4 2024-2025--Toyota Tacoma TRD PreRunner 2.4 L4 2024-2025--Toyota Tacoma TRD Sport 2.4 L4 2024-2025
TechSpec Chassis Codes: N/A
TechSpec Core Height (in): 27.8
TechSpec Core Length (in): 24.4
TechSpec Core Thickness (in): 1.6
TechSpec DPI: N/A
TechSpec Drain Plug Thread Size: M12x1.5
TechSpec Engine Codes: N/A
TechSpec Fluid Capacity (gal): N/A
TechSpec Includes: N/A
TechSpec Inlet (in): 1.3
TechSpec Material: Aluminum
TechSpec Note: Does not fit TRD Pro Trailhunter or Tacoma trucks optioned with the i-Force Max hybrid engine
TechSpec Outlet (in): 1.3
TechSpec Overall Height (in): 28.9
TechSpec Overall Length (in): 31.6
TechSpec Overall Width (ins): 5.4
TechSpec Rows: N/A
