Performance Aluminum Radiator, fits Ford Ranger 2.3L 2019 - 2023 - Mishimoto - MMRAD-RGR-19

The 2019 - 2023 Ford Ranger 2.3L EcoBoost is one of the most capable small trucks on the planet and it deserves a cooling system that's equally capable. This Mishimoto Performance Aluminium Radiator is constructed from high-quality aluminium with precision TIG-welded end tanks for increased durability and resistance to heat and pressure. The direct-fit design means this radiator fits without any trimming or modifications. To make sure our radiator performs as well as it fits we've also increased its core volume by 78 percent and its fluid capacity by 51.3 percent. Core thickness is increased by 43.7 percent and external fin surface area is increased by 95 percent to make the most of the air coming through the grille. This Mishimoto 2019 - 2023 Ford Ranger 2.3L EcoBoost Performance Aluminium Radiator includes a magnetic drain plug to keep your coolant free of metallic debris and is backed by our Mishimoto Lifetime Warranty to keep your Ranger cool as long as you own it.
Increases core volume by 78-percent over stock radiator
Increases fluid capacity by 51.3-percent over stock radiator
43.7-percent thicker core than stock radiator
Drain Plug Thread Size: M12 - 1.5
Core Finish: Uncoated
Drain Plug Included: Yes
Overall Height: 0 IN
Core Height: 26.18 IN
Core Thickness: 1.89 IN
Core Material: Aluminum
Outlet Location: Bottom Left
Transmission Oil Cooler Included: No
Transmission Oil Cooler Fitting Type: N/A
Radiator Cap Included: No
Core Length: 23.22 IN
Core Row Quantity: 2
Inlet Diameter: 0 IN
Inlet Location: Top Right
Outlet Diameter: 0 IN
Fluid Capacity: 3.39 GA
Down Flow Or Cross Flow Type: Cross Flow
Overall Length: 0 IN
Overall Width: 0 IN
Install Difficulty: 2
Prop 65 - Short Label: WARNING: Cancer and Reproductive Harm - www.p65warnings.ca.gov
Prop 65 Y/N: Y
SellingPoint01: Direct fit for 2019 - 2023 Ford Ranger 2.3L EcoBoost
SellingPoint02: Increases core volume by 78-percent over stock radiator
SellingPoint03: Increases fluid capacity by 51.3-percent over stock radiator
SellingPoint04: 43.7-percent thicker core than stock radiator
SellingPoint05: 95-percent increase in fin surface area
SellingPoint06: Full aluminum construction with durable TIG-welded end tanks
SellingPoint07: Includes Magnetic Drain Plug to capture any metallic debris/fragments in your cooling system
SellingPoint08: Mishimoto Lifetime Warranty
SellingPoint09: N/A
SellingPoint10: N/A
SellingPoint11: N/A
SellingPoint12: N/A
SellingPoint13: N/A
SellingPoint14: N/A
SellingPoint15: N/A
TechSpec Applications: 2019 - 2023 Ford Ranger 2.3L EcoBoost
TechSpec Chassis Codes: T6
TechSpec Core Height (in): 26.18
TechSpec Core Length (in): 23.22
TechSpec Core Thickness (in): 1.89
TechSpec DPI: N/A
TechSpec Drain Plug Thread Size: M12 x 1.5
TechSpec Engine Codes: N/A
TechSpec Fluid Capacity (gal): 3.39
TechSpec Includes: Mishimoto Performance Aluminum Radiator-- Mishimoto Magnetic Drain Plug--Mounting Hardware--Mishimoto Lifetime Warranty
TechSpec Inlet (in): N/A
TechSpec Material: Aluminum
TechSpec Note: This radiator reuses the factory mounting grommets. If your grommets are damaged you may purchase replacements under Ford part #EB3Z-6C681-B
TechSpec Outlet (in): N/A
TechSpec Overall Height (in): N/A
TechSpec Overall Length (in): N/A
TechSpec Overall Width (in): N/A
TechSpec Rows: 2
