Ford 6.7L Powerstroke Baffled Oil Catch Can Kit, 2017-2022 - Mishimoto - MMBCC-F2D-17BE

High-output engines require high-flow crankcase ventilation. Our high-flow catch can utilizes a high-capacity bottom with a 5.3 fl. oz. capacity. The CNC-machined lid includes large M27 x 2.0 inlets and outlets to let your crankcase breathe. Inside the can is a CNC-machined baffle with integrated filter that lets crankcase gases flow through while filtering out potentially harmful fuel oil and water vapors. Like our compact baffled oil catch can our high-flow catch can and filter are fully serviceable for easy draining and cleaning. To make this kit a direct fit for your 2017-2022 Ford 6.7L Powerstroke Mishimoto includes a custom-engineered 3mm-thick steel bracket. This bracket mounts the can in an easy to access location for quick servicing. To withstand the rigors of life under the hood of your 6.7L our bracket is gusseted and powder-coated black for the highest strength and resistance to the elements. Also included with this kit is a set of direct-fit hoses and adapters that allow the catch can to tap into the stock CCV breather box and carry blow-by away from your engine. For even more protection this 2017-2022 Ford 6.7L Powerstroke Baffled Oil Catch Can is backed by our Mishimoto Lifetime Warranty.
Direct-fit for 2017-2022 Ford 6.7L Powerstroke
High-flow catch can allows your crankcase to breathe while filtering out harmful oil fuel and water vapors
Sturdy 3mm thick steel bracket mounts the catch can in an easily accessible location for easy servicing
Can Material: 6061-T6 Billet Aluminum
Can Type: Twist Off
Can Outside Diameter: 3.5 IN
Inlet Port Quantity per Can: 1
Outlet Port Quantity per Can: 1
Can Finish: Anodized
Hose Included: Yes
Color: Black
Outlet Port Inside Diameter: 1.1 IN
Inlet Port Inside Diameter: 1.1 IN
Drain Plug Included: Yes
Finish: Anodized
Height: 3 IN
Maximum Can Capacity: 5.3 FO
Interior Baffle: Yes
Mounting Bracket Included: Yes
Finish: Powder-Coat
Install Difficulty: 4
Installation Difficulty: 2
Prop 65 - Short Label: WARNING: Cancer and Reproductive Harm - www.p65warnings.ca.gov
Prop 65 Y/N: Y
SellingPoint01: Direct-fit for 2017-2022 Ford 6.7L Powerstroke
SellingPoint02: High-flow catch can allows your crankcase to breathe while filtering out harmful oil fuel and water vapors
SellingPoint03: Sturdy 3mm thick steel bracket mounts the catch can in an easily accessible location for easy servicing
SellingPoint04: CNC-machined adapters retain the stock CCV filter box for a sleek install while intercepting and re-routing blow-by away from the intake
SellingPoint05: Includes durable CNC-machined aluminum hose barb fittings
SellingPoint06: 5.3 fl. oz. capacity for improved flow and extended service intervals
SellingPoint07: Powder-coated bracket for maximum durability in all conditions
SellingPoint08: Filter and can are fully serviceable
SellingPoint09: Patent No. US D884 761
SellingPoint10: Mishimoto Lifetime Warranty
SellingPoint11: N/A
SellingPoint12: N/A
SellingPoint13: N/A
SellingPoint14: N/A
SellingPoint15: N/A
TechSpec Applications: Ford F-250 6.7 V8 2017-2022--Ford F-350 6.7 V8 2017-2022--Ford F-450 6.7 V8 2017-2022--Ford F-550 6.7 V8 2017-2022
TechSpec Catch Can Diameter (in): N/A
TechSpec Chassis Codes: N/A
TechSpec Drain Plug Thread Size: N/A
TechSpec Engine Codes: N/A
TechSpec Height (in): N/A
TechSpec Includes: N/A
TechSpec Inlet: N/A
TechSpec Installation Notes: N/A
TechSpec Material: N/A
TechSpec Note: This catch can kit is designed to work with the stock CCV filter box installed. This kit will not fit with other CCV delete or reroute kits. If you need to purchase the OEM CCV filter box for your vehicle the part number is: GC4Z-6A785-D--After installation Mishimoto recommends checking the contents of the baffled catch can every 1 000 miles until a baseline is established. Oil blow-by accumulation will vary with ambient temperatures and driving conditions. It is important that the contents of the can do not rise above the internal baffle.
TechSpec Outlet: N/A
Title: Mishimoto Ford 6.7L Powerstroke Baffled Oil Catch Can Kit 2017-2022
