3" Cat Back, Single Side Exit, AL - MBRP Exhaust - S5223AL

THE BEST BANG FOR YOUR BUCK - ARMOR LITE Series exhaust systems are a value option with the same fitment performance and sound as the premium products from MBRP.and#x0D; Heavy-gauge Aluminized Steel tubing helps to resist dings and dents caused by debris under your vehicle. This material can be a great choice for you if you live in a dry climate that doesn’t see much precipitation or if you’re looking for great sound on a budget. All of the tubing is mandrel bent for maximum exhaust flow. Mandrel bending ensures no rippling in the bends. The end result is that it gives you more fresh air inside your engine’s cylinders allowing it to produce more power and improve vehicle performance and longevity. MBRP Stand out from the crowd with a performance exhaust system that sounds great.
Heavy Duty Aluminized Steel Fully Sealed Tubing for Rust Resistance. Bolt-on Installation. MBRP Signature Styling and Design.
Built to Perform MBRP's performance exhaust systems are built to perform. Designed to maximize exhaust flow and minimize exhaust temperatures your truck will use less gas last longer and perform better. Every system we sell has been built to the most exacting standards in the industry.
Dyno Proven
Your MBRP performance gas exhaust system has undergone countless hours on our in-house Mustang 1100 AWD-SE Chassis Dynamometer hundreds of miles on road and track and numerous tweaks and modifications to get the most out of your truck. From the vehicle specific muffler design to the fully mandrel bent tubing to minimal bend degree angles your MBRP performance system gets exhaust out fast. An MBRP performance exhaust system is the starting point to getting the most from cold air intakes programmers modules and downloaders.
Exhaust Tip Length: 12 IN
Exhaust Tip Quantity: 2
Exhaust Tip Diameter: 4 IN
Exhaust Tip Finish: Polished
Exhaust Tip Material: Stainless Steel
Tip Shape: Round
Clamps Included: Yes
Finish: Polished
Gasket Or Seal Included: No
Pipe Material: Aluminized Steel
Clamping Type: Round Band
Hangers Included: Yes
Muffler Flanged Inlet: No
Tail Pipe Outlet Outside Diameter: 2.5 IN
Tail Pipe Tapered Outlet: No
Muffler Body Material: Aluminized Steel
Muffler Body Shape: Round
Muffler Quantity: 1
Muffler Outlet Quantity: 1
Tail Pipe Quantity: 2
Inlet Type: Bolt-on
Exit Style: Dual Split Rear
Main Piping Diameter: 2.5 IN
Exhaust Tip Connection: Bolt-on
Exhaust Tip Wall: Single
Exhaust Tip Cut: Angled
Exhaust Tip Edge: Rolled End
Exhaust Tip Resonated: No
Exhaust Tip Intercooled: No
Muffler Finish: Polished
Bolt-On Yes/No: Yes
Cutting Required: Cutting May Be Required
Dual-Out Diameter: 2.5 Inch
Exit Style: Dual Rear Exit
Fuel Type: Gasoline
Horsepower Increase (HP): 15
Major: Performance Gas
Material: Aluminized Steel
MBRP Series: Armor Lite
Minor: Dual
Muffler Yes/No: Yes
Profile: Street Profile
Prop 65 (C R or CR): CR
Prop 65 - Short Label: Prop65warning.pdf
Prop 65 Yes/No: YES
Single-In Diameter: 3 Inch
Title: MBRP Exhaust 3 inch Cat Back Single Side Exit AL
Torque Increase (FTLB): 14
Type: Cat-Back
UPS Able: Yes
Vehicle Segment: Truck

Detailed Fitment Results
Year Make Model Engine Size Sub Model Body Type 2019 Ford Ranger 2.3 Lariat / XL / XLT Crew Cab Pickup / Extended Cab Pickup 2020 Ford Ranger 2.3 Lariat / XL / XLT Crew Cab Pickup / Extended Cab Pickup 2021 Ford Ranger 2.3 XL Extended Cab Pickup 2022 Ford Ranger 2.3 Lariat / XL / XLT Crew Cab Pickup / Extended Cab Pickup 2023 Ford Ranger 2.3 XL / XLT / Lariat Extended Cab Pickup / Crew Cab Pickup
