20-23 Ford Ranger Suspension Lift Kit - Front and Rear - ICON Vehicle Dynamics - K93204TS

SUSPENSION SYSTEM
K93204TS
Factory Wheels and Tires Fitment: Yes
Recommended Aftermarket Wheels: ICON Alloys - 17x8.
5" w/ 5.
75” Backspace / 25mm Offset
Recommended Aftermarket Wheels: ICON Alloys - 18x9" w/ 6.
00” Backspace / 25mm Offset
Recommended Aftermarket Tires: 33"x11.
25" (Larger Tires May Fit but Fender Trimming and Modifications will be Required)
APPLICATION NOTE #55: Shocks Are Fully Serviceable.
Coilover Heights Indicated Are For A Stock Equipped Vehicle
APPLICATION NOTE #110: Minor Trimming Required For Recommended Tire Size
TECH NOTE: Compatible with 2020-2023 Rangers equipped with steel knuckles only
TECH NOTE: Ranger XLT or Lariat models equipped with Tremor package have front lift height range of 0-2.
5" over stock.
TECH NOTE: Not compatible with Ranger Raptor.
20-23 FORD RANGER 0-3.
5" STAGE 4 SUSPENSION SYSTEM W TUBULAR UCA STEEL KNUCKLE
ICON complete suspension systems lift your Ford Ranger while improving ride quality and performance.
With endless hours spent testing and tuning our suspension components and shocks, you’ll have the best suspension solution on the market.
ICON Vehicle Dynamics 2020-2023 Ford Ranger suspension systems are designed to dramatically increase the on and off-road ride quality.
ICON engineers’ primary focus is to increase wheel travel and damping ability, which translates into outstanding vehicle control and ride quality both on and off-road.
With wheel travel and ride quality in mind, ICON engineers researched each component of the new Ranger platform’s suspension and addressed any areas where performance could be extracted.
The Stage 4 (Tubular) system includes vehicle-specific tuned, extended travel 2.
5 Series coilover shocks featuring remote reservoirs for exceptional cooling properties and ICON-engineered coil springs for superior vehicle “feel” through the range of travel.
These coilovers are also height adjustable from 0-3.
5” allowing the use of larger, more aggressive wheel and tire combinations.
The included ICON tubular upper control arm kit is designed to improve the overall performance with corrected front-end geometry, built in additional caster, and improved suspension component clearance.
Additionally, replacing the OE ball joint with the ICON Delta Joint allows for full bump and extended droop travel of the front suspension while eliminating bind.
ICON 2.
5 Aluminum Series piggyback reservoir rear shocks utilize a vehicle-specific valving that balances the performance of the truck from front to rear while the included foam bump stop kit increases rear end compliance.
The ICON Vehicle Dynamics 2020-2023 Ford Ranger Stage 4 suspension system is an excellent choice for those drivers looking to enhance the capabilities of their pickup on the road as well as in the dirt.
This system features tubular steel upper control arms with ICON's patented Delta Joint.
The Delta Joint is a heavy-duty high angle ball joint that combines the durability of a ball joint with the performance characteristics of a traditional uniball.
While the industry standard uniball does a great job of allowing the control arms of a vehicle to articulate with little bind, they do have an inherent weakness that leaves more to be desired when used in a daily driven application - exposure to the elements.
The Delta Joint features a zinc plated housing providing the first layer of corrosion resistance, while a tough grease seal keeps potentially harmful elements out of the inner workings of the joint.
Metal on metal construction and a greaseable design increase the longevity of the Delta Joint while at the same time allowing for noise-free operation.
What makes the Delta Joint unique is that it brings the best of both worlds to ICON upper control arms with features that make it more robust than a uniball, and at the same time capable of greater angularity than a typical ball joint.
Height-adjustable coilovers provide a range of 0-3.
5” of front lift height
Fits 2WD and 4WD applications
Increased lift height allows for fitment of larger and more aggressive tires
35% increase in front wheel travel over stock
ICON shocks feature vehicle specific tune for superior performance and ride quality
Corrosion resistant CAD plated shock body with 7/8" shaft (2.
5 Series coilovers)
Corrosion resistant hard anodized shock body with 7/8" shaft (2.
5 Aluminum Series rear shocks)
FK Rod End bearings provide extended longevity and minimal deflection
Shocks are fully rebuildable and revalvable
ICON upper control arms allow for additional wheel travel (when paired with extended travel coilovers) while improving suspension geometry for predictable handling
Patented Delta Joint (U.
S.
Pat.
10,731,700) combines the durability and weather resistance of a ball joint with the performance characteristics of a uniball
Delta Joint ball joints carry ICON's exclusive 5 year limited warranty
Direct bolt-in design makes for a simple and straightforward installation
Lifetime guarantee against ICON fabricated component and coil spring breakage or manufacturer defect
ICON 2020-2023 Ford Ranger, 0-3.
5" Lift, Stage 4 Suspension System, Tubular UCA for Steel Knuckle, K93204TS
ICON 20-23 Ford Ranger, 0-3.
5" Lift, Stage 4 Susp Sys, Tubular UCA Steel Knuckle
ICON 20-23 FORD RANGER 0-3.
5" STAGE 4 SUSPENSION SYSTEM W TUBULAR UCA STEEL KNUCKLE.

Detailed Fitment Results
Year Make Model Submodel Fitment Notes 2020 Ford Ranger XL Recommended Aftermarket Wheel Size: 17x8.5 inch with 5.75” Backspace / 25mm Offset 2020 Ford Ranger XLT Recommended Aftermarket Wheel Size: 17x8.5 inch with 5.75” Backspace / 25mm Offset 2020 Ford Ranger Lariat Recommended Aftermarket Wheel Size: 17x8.5 inch with 5.75” Backspace / 25mm Offset 2021 Ford Ranger XL Recommended Aftermarket Wheel Size: 17x8.5 inch with 5.75” Backspace / 25mm Offset 2021 Ford Ranger XLT Recommended Aftermarket Wheel Size: 17x8.5 inch with 5.75” Backspace / 25mm Offset 2021 Ford Ranger Lariat Recommended Aftermark…
