Ford (4WD) Suspension Lift Kit - Front and Rear - ICON Vehicle Dynamics - K67104

SUSPENSION SYSTEM
05-07 F-250/F-350 7" STAGE 5 SYSTEM
OEM Wheels and Tires Fitment: Yes
Recommended Aftermarket Wheels: ICON Alloys - 17x8.
5" w/ 5.
00” Backspace / 6mm Offset
Recommended Aftermarket Wheels: ICON Alloys - 18x9" w/ 5.
25” Backspace / 6mm Offset
Recommended Aftermarket Wheels: ICON Alloys - 20x9" w/ 5.
25” Backspace / 6mm Offset
Recommended Aftermarket Tires: 37" x 12.
50" (Larger tires may fit but fender trimming and modifications will be required.
)
APPLICATION NOTE #6: Springs Are Rated For Diesel Engines Only
APPLICATION NOTE #21: Not Applicable On Vehicles Equipped With A Manual Transmission
APPLICATION NOTE #28: Pinch Weld On ‘05-’10 Superduty Radius Arms May Come In Contact With Radius Arm Drop Bracket Hardware
APPLICATION NOTE #29: 7” Systems Using A 4-Link In Place Of The Factory Radius Arms Do Not Require The Use Of Alignment Cams.
Caster Can Be Adjusted By The Lower Link Arms
APPLICATION NOTE #55: Shocks Are Fully Serviceable.
Coilover Heights Indicated Are For A Stock Equipped Vehicle
APPLICATION NOTE #57: Retains Factory Block For Truck To Sit Level With Front Of Truck
Ships in multiple boxes
05-07 FORD F-250/F-350 7" STAGE 5 SUSPENSION SYSTEM
2005-2007 FORD F-250/F-350 7" LIFT STAGE 5 SUSPENSION SYSTEM
This ICON Vehicle Dynamics 7” suspension system is a great way to lift your 4WD 2005-2007 Ford F250/350 Super Duty while drastically improving ride quality and performance.
This suspension system is perfect for on-road and off-road use including towing, job site duty, and provides ultimate performance for extreme off-road adventure.
ICON's 7" Stage 5 System is comprised of dual rate coil springs, progressive leaf springs, 4-Link kit, ICON CDC Valve 2.
5 Aluminum Series piggyback reservoir front and rear shocks, plus all of the necessary hardware for installation.
The Stage 5 system sees the inclusion of the ICON Vehicle Dynamics Ford Super Duty 4-Link kit, which further improves performance by eliminating suspension bind commonly experienced with factory radius arms during articulation.
This “freeing up” of the front end and the ability of the 4-Link Kit to maintain positive caster through the range of travel equates to an unparalleled ride quality in all conditions.
With the endless hours ICON has spent testing and tuning our suspension components and shocks as a complete package, you can rest assured knowing that you have the best suspension solution on the market.
Approximately 50% increased front wheel travel over stock
Lifetime guarantee against coil spring breakage or sag
Lifetime guarantee against ICON fabricated component breakage or manufacturer defect
ICON-engineered dual rate coil springs deliver exceptional vehicle control over varying terrain
Progressive leaf springs improve ride quality without reducing towing capacity
ICON 4-Link system eliminates binding during articulation and maintains positive caster through the entire range of travel
ICON CDC Valve allows for 10 clicks of quick and easy compression adjustability
ICON shocks feature vehicle specific tune for superior performance and ride quality
Shocks are fully rebuildable and re-valvable
One-piece impact extruded aluminum cylinders offer excellent corrosion resistance and consistent finish
FK Rod End bearings provide extended longevity and minimal deflection
ICON 2005-07 Ford F250/F350, 7" Lift, Stage 5 Suspension System, K67104
ICON 2005-07 Ford F250/F350, 7" Lift, Stage 5 Suspension System.

Detailed Fitment Results
Year Make Model 2005 Ford F-250 Super Duty 2005 Ford F-350 Super Duty 2006 Ford F-250 Super Duty 2006 Ford F-350 Super Duty 2007 Ford F-250 Super Duty 2007 Ford F-350 Super Duty
