Ford (4WD) Suspension Lift Kit - Front and Rear - ICON Vehicle Dynamics - K67100

SUSPENSION SYSTEM
05-07 F-250/F-350 7" STAGE 1 SYSTEM
OEM Wheels and Tires Fitment: Yes
Recommended Aftermarket Wheels: ICON Alloys - 17x8.
5" w/ 5.
00” Backspace / 6mm Offset
Recommended Aftermarket Wheels: ICON Alloys - 18x9" w/ 5.
25” Backspace / 6mm Offset
Recommended Aftermarket Wheels: ICON Alloys - 20x9" w/ 5.
25” Backspace / 6mm Offset
Recommended Aftermarket Tires: 37" x 12.
50" (Larger tires may fit but fender trimming and modifications will be required.
)
APPLICATION NOTE #6: Springs Are Rated For Diesel Engines Only
APPLICATION NOTE #21: Not Applicable On Vehicles Equipped With A Manual Transmission
APPLICATION NOTE #28: Pinch Weld On ‘05-’10 Superduty Radius Arms May Come In Contact With Radius Arm Drop Bracket Hardware
APPLICATION NOTE #29: 7” Systems Using A 4-Link In Place Of The Factory Radius Arms Do Not Require The Use Of Alignment Cams.
Caster Can Be Adjusted By The Lower Link Arms
APPLICATION NOTE #55: Shocks Are Fully Serviceable.
Coilover Heights Indicated Are For A Stock Equipped Vehicle
APPLICATION NOTE #56: Rear Add-A-Leaf Required For Truck To Sit Level When Using 6” Block Included In Kit
Ships in multiple boxes
05-07 FORD F-250/F-350 7" STAGE 1 SUSPENSION SYSTEM
2005-2007 FORD F-250/F-350 7" LIFT STAGE 1 SUSPENSION SYSTEM
ICON’s 7” Suspension System for the 2005-2007 Ford Super Duty offers unparalleled performance and ride quality while giving the vehicle clearance for 38” Tall tires.
This system comes complete with ICON 2.
0 Aluminum Series Shocks, Dual Rate Coil Springs, Drop Pitman Arm, Pan Rod Bracket, Brake Line Brackets, Radius Arm Drop Down Brackets, ICON's Fabricated 6" Blocks and U-bolts.
All of these components (excluding shocks) are covered by ICON’s Limited Lifetime Warranty.
75% increase in wheel travel
Less body roll than stock
7” more travel from ride height to front bump stops
State of the art dual-rate coil spring
Lifetime guarantee that coil springs won’t sag
Clears 38" Tall Tires
No change in towing capacity
No drive shaft modifications needed
100% Bolt-on system - No drilling, cutting, or welding necessary
ICON 2005-07 Ford F250/F350, 7" Lift, Stage 1 Suspension System, K67100
ICON 2005-07 Ford F250/F350, 7" Lift, Stage 1 Suspension System.

Detailed Fitment Results
Year Make Model 2005 Ford F-250 Super Duty 2005 Ford F-350 Super Duty 2006 Ford F-250 Super Duty 2006 Ford F-350 Super Duty 2007 Ford F-250 Super Duty 2007 Ford F-350 Super Duty
