2023-2025 Ford F-250/F-350 Super Duty 4WD Gas 2.5 Inch Lift Stage 6 Suspension System W/ 4-Link - ICON Vehicle Dynamics - K65919

This ICON Vehicle Dynamics 2.5 Inch suspension system is a great way to lift your 4WD 2023-2025 Ford F-250/F-350 Super Duty while drastically improving ride quality and performance. The Stage 6 system is perfect for on-road and off-road use including towing, job site duty and general off-road adventure.

ICON's Stage 6 System is comprised of dual rate coil springs optimized for trucks equipped with gasoline engines, dual steering stabilizer kit with ICON 2.0 Aluminum Series stabilizers, on-vehicle adjustable front track bar, fabricated radius arms, and ICON 2.5 Aluminum Series CDEV remote reservoir front and CDEV piggyback reservoir rear shocks. Focus on driving and let ICON Intelligent Control (IIC) read the terrain and make near-instant adjustments via the Compression Damping Electronic Valve (CDEV) at each individual shock.

Control the system wirelessly through the IIC app on your phone and once configured the system functions without driver input. This stage sees the inclusion of the ICON Vehicle Dynamics Ford Super Duty 4-Link kit further improving performance by eliminating suspension bind commonly experienced with factory radius arms during articulation and allows on-vehicle caster angle adjustment.

This Inchfreeing up Inch of the front end and the ability of the 4-Link Kit to maintain positive caster through the range of travel equates to an unparalleled ride quality in all conditions. With the endless hours ICON has spent testing and tuning our suspension components and shocks as a complete package, you can rest assured you have the best suspension solution on the market.

Features and Benefits:


Fits 2023-2025 F-250 / F-350 4WD gas applications

Approximately 25 Percent increased front wheel travel over stock

ICON-engineered dual rate coil springs deliver exceptional vehicle control over varying terrain

ICON 4-Link system eliminates binding during articulation and maintains positive caster through the entire range of travel

ICON shocks feature vehicle specific tune for superior performance and ride quality

ICON's CDE Valve technology allows for in vehicle adjustment of compression damping settings and active adjustment via the ICON Intelligent Control (IIC)

ICON Intelligent Control (IIC) uses onboard sensors to monitor G-forces and movement of vehicle chassis along with user defined settings to actively make near instantaneous compression damping changes

ICON 2.5 Centerline steering stabilizer kit with piggyback reservoir offers increased steering damping

Shocks are fully rebuildable and revalvable

Hard anodized, corrosion resistant, one-piece impact extruded aluminum shock bodies with 7/8 Inch shafts

FK Rod End bearings provide extended longevity and minimal deflection

Lifetime guarantee against coil spring breakage or sag

Lifetime guarantee against ICON fabricated component breakage or manufacturer defect


Details


Active Or Passive Suspension: Active

Adjustable Compression: Yes

Adjustable Control Arm: Yes

Adjustable Damping: Yes

Adjustable Rebound: No

Bushings Included: Yes

Coil Quantity Front: 2.0

Coil Spring Color: Black

Coil Spring Material: Steel

Coils Quantity Front: 2.0

Damping Adjustment Type: Electronic

Front Reservoir Style: Remote

Front Shock Body Diameter: 2.5

Front Spring Rate Type: Progressive Dual Rate

Grade Type: Performance

Leaf Spring Material: Steel

Maximum Lift: 2.5 Inch

Maximum Lift Front: 2.5 Inch

Maximum Lift Height Front: 2.5 Inch

Minimum Lift Front: 1.5 Inch

Mounting Hardware Included: Yes

Oem Wheels & Tires Fitment: Yes

Rear Reservoir Style: Piggyback

Rear Shock Body Diameter: 2.5

Recommended Aftermarket Tires: 35 Inch X 12.50 Inch (Larger Tires May Fit But Fender Trimming And Modifications Will Be Required)

Recommended Aftermarket Wheels: Icon Alloys - 20x9 Inch W/ 5.25 Inch Backspace / 6mm Offset, Icon Alloys - 18x9 Inch W/ 5.25 Inch Backspace / 6mm Offset, Icon Alloys - 17x8.5 Inch W/ 5 Inch Backspace / 6mm Offset

Shocks Included: Yes

Spring Color: Black

Spring Material: Steel

Add On Part: 191014 - .25 Inch Collar Spanner Pin Wrench, 252012 - -4 To -10 Hose Shield Kit, 61111 - 17-25 FSD Front 2.5 Inch Extended Ss Brake Line Kit
