2025 Toyota 4Runner 4WD 1.25-3 Inch Lift Stage 1 Suspension System - ICON Vehicle Dynamics - K53401

ICON Vehicle Dynamics 2025 Toyota 4Runner suspension systems are designed with maximum performance and the serious driver in mind. ICON engineers' primary focus is to increase wheel travel and damping ability, which translates into outstanding vehicle control and ride quality both on- and off-road.

The Stage 1 system includes vehicle-specific tuned 2.5 Series coilover shocks featuring internal reservoirs for exceptional cooling properties and ICON-engineered coil springs for superior vehicle Inchfeel Inch through the range of travel. These coilovers are height adjustable from 1.25-3 Inch of front lift height over stock, allowing the use of larger, more aggressive wheel and tire combinations.

The combination of front differential drop brackets and ICON's specifically designed coilover lengths maximizes the available front suspension travel and prevent CV bind. Additionally, polyurethane differential mounting bushings replace the soft OE bushings to help limit differential movement under load.

The dual-rate rear coil design provides a softer ride height spring rate with a firmer overload rate that combine to deliver on-road comfort with excellent bottoming resistance and superior off-road performance while .75 Inch of rear lift height over stock allows a for level stance front to rear. ICON 2.0 Aluminum Series internal reservoir rear shocks utilize a vehicle-specific valving that balances the performance of the truck from front to rear.

The ICON Vehicle Dynamics 2025 Toyota 4Runner Stage 1 suspension system is an excellent choice for those drivers looking to enhance the capabilities of their pickup on the road as well as in the dirt.

Features and Benefits:


Vehicle specific tuned front and rear shocks for superior shock damping and control

Increased wheel travel and improved ride quality over stock

Front differential drop provides better maximum operating angle for CV joints and maximizes available wheel travel

Adjustable 2.5 Series coilovers provide 1.25-3 Inch front lift height over stock

6061 aircraft grade aluminum CNC machined components

Corrosion resistant CAD plated coilover shock bodies with 7/8 Inch shafts

Dual rate rear coil springs improve performance and ride quality while providing .75 Inch of rear lift

FK Rod End bearings for extended longevity and minimal deflection

2.0 Aluminum Series internal reservoir rear shocks with 5/8 Inch shafts


Details


Active Or Passive Suspension: Passive

Adjustable Compression: No

Adjustable Damping: No

Adjustable Rebound: No

Bushings Included: Yes

Coil Quantity Front: 2.0

Coil Spring Color: Black

Coil Spring End 1 Type: Closed

Coil Spring End 2 Type: Closed

Coil Spring Material: Steel

Coils Quantity Front: 2.0

Coils Quantity Rear: 2.0

Front Reservoir Style: Internal

Front Shock Body Diameter: 2.5

Front Spring Rate Type: Linear

Grade Type: Performance

Maximum Lift: 3.0 Inch

Maximum Lift Front: 3.0 Inch

Maximum Lift Height Front: 3.0 Inch

Maximum Lift Height Rear: 0.75 Inch

Maximum Lift Rear: 0.75 Inch

Minimum Lift Front: 1.25 Inch

Mounting Hardware Included: Yes

Oem Wheels & Tires Fitment: Yes

Rear Reservoir Style: Internal

Rear Shock Body Diameter: 2.0

Rear Spring Rate Type: Progressive Dual Rate

Recommended Aftermarket Tires: 33 Inch X 11.50 Inch (Larger Tires May Fit But Fender Trimming And Modifications Will Be Required)

Recommended Aftermarket Wheels: 17x8.5 With 6.32 Inch Backspace / 40mm Offset, Icon Alloys - 18x9 With 6.6 Inch Backspace / 40mm Offset

Reservoir Style: Internal

Shocks Included: Yes

Spring Color: Black

Spring Material: Steel

Add On Part: 198000 - 2 Pin Coilover Spanner Wrench Kit, 58552Gdj - 24-25 Tacoma/24-25 Lc250/24-25 Gx550/25 T4R Billet UCA Dj Pro Kit Gold Ano, 54202 - 22-25 Tundra/23-25 Sequoia/24-25 Taco/Lc250/Gx550/25 T4R Blt Adj Track Bar, 198001 - Billet Spanner Wrench Kit, 191009 - Icon Long 2.5 Coil Wrap W/Logo (14.5-15.5), 58452Dj - 24-25 Tacoma/24-25 Lc250/24-25 Gx550/25 T4R Tubular UCA Dj Pro Kit, 58552Dj - 24-25 Tacoma/24-25 Lc250/24-25 Gx550/25 T4R Billet UCA Dj Pro Kit, 56100 - 07-14 FJ Cruiser 03-25 4Runner/22-25 Tundra/23-25 Sequoia Rear Shin Guards, 56120 - 24-25 Land Cruiser 250 Series/25 4Runner Front Skid Plate, 56121 - 24-25 Land Cruiser 250 Series/25 4Runner Hybrid Trans Skid Plate, 56122 - 24-25 Land Cruiser 250 Series/25 4Runner Front Skid Plate Fascia, 56117 - 24-25 Tacoma/25 4Runner Gas Transmission Skid Plate



Detailed Fitment Results
Year Make Model Engine Fuel 2025 Toyota 4Runner 2.4L GAS
