00-05 Ford Excursion (4WD) Suspension Lift Kit - Front and Rear - ICON Vehicle Dynamics - K45000-99

SUSPENSION SYSTEM
K45000-99
OEM Wheels and Tires Fitment: Yes
Recommended Aftermarket Wheels: ICON Alloys - 17x8.
5" w/ 5.
00” Backspace / 6mm Offset
Recommended Aftermarket Wheels: ICON Alloys - 18x9" w/ 5.
25” Backspace / 6mm Offset
Recommended Aftermarket Wheels: ICON Alloys - 20x9" w/ 5.
25” Backspace / 6mm Offset
Recommended Aftermarket Tires: 35" x 12.
50" (Larger tires may fit but fender trimming and modifications will be required.
)
APPLICATION NOTE #1: Front U-Bolt Note: All Front Springs Come Complete With Front U-Bolts, Washers, And Nuts.
When Ordering Any Front Spring System From ICON Vehicle Dynamics Please Specify Manufacture Year.
APPLICATION NOTE #3: No Front Driveshaft Modification Needed.
Stock Driveshaft Is Fully Functional.
APPLICATION NOTE #6: Springs Are Rated For Diesel Engines Only
APPLICATION NOTE #17: These Are Stand-Alone Kits And Are Not To Be Used In Conjunction With Any Other Aftermarket Kits
00-05 FORD EXCURSION 5" SUSPENSION SYSTEM
2000-2005 FORD EXCURSION 5" LIFT SUSPENSION SYSTEM
This system is designed to lift your 2000-2005 Ford Excursion 5" in the front and provide room for 35” tires.
This system uses custom progressive spring packs front and rear for ultimate ride quality, while providing 5" of lift.
This system comes with a 1.
75" bump stop spacer (not pictured) to prevent spring fatigue during the suspension cycle.
Also included in this kit is 5” rear block kit, with 12” U-bolts for a leveled stance.
Increased wheel travel
Durable powder coat finish
Less body-roll than stock truck
No change in towing capacity
No drive shaft modifications needed
100% Bolt-on system - no drilling, cutting or welding necessary for install
ICON 2000-2005 Ford Excursion, 5" Lift, Suspension System, K45000-99
ICON 2000-2005 Ford Excursion, 5" Lift, Suspension System
ICON 00-05 FORD EXCURSION 5" SUSPENSION SYSTEM.

Detailed Fitment Results
Year Make Model 2000 Ford Excursion 2001 Ford Excursion 2002 Ford Excursion 2003 Ford Excursion 2004 Ford Excursion 2005 Ford Excursion
