2014 Ford F-150 (RWD) Coilover Spring and Shock Assembly - Front - ICON Vehicle Dynamics - 91615

F150 COILOVER KIT
F150 2WD 0-2.
63" 2.
5 VS IR COILOVER KIT
Factory Wheels and Tires Fitment: Yes
Recommended Aftermarket Wheels: ICON Alloys - 17x8.
5" w/ 5.
00” Backspace / 6mm Offset
Recommended Aftermarket Wheels: ICON Alloys - 18x9" w/ 5.
25" Backspace / 6mm Offset
Recommended Aftermarket Wheels: ICON Alloys - 20x9" w/ 5.
625" Backspace / 16mm Offset
Recommended Aftermarket Tires: 33" x 11.
50" (Larger Tires May Fit but Fender Trimming and Modifications will be Required)
2014 F150 2WD 0-2.
63" 2.
5 VS IR COILOVER KIT
2014 FORD F150 2WD 0-2.
63" LIFT 2.
5 VS INTERNAL RESERVOIR COILOVER KIT
ICON Vehicle Dynamics V.
S.
Series 2.
5” coilover shocks are an incredible upgrade for the front end of 2014 F150 2WD trucks.
ICON’s Vehicle-specific valving provides a sport tuned feel on and off-road while 0-2.
63” of lift height adjustability allows the use of larger, more aggressive wheel and tire combinations.
The larger 2.
5” shock body and increased piston area over stock components provides improved damping ability and outstanding ride characteristics across varying types of terrain.
When paired with ICON rear 2.
0 Aluminum Series or 2.
5 Series shocks, vehicle control will be balanced front to rear resulting in the best overall driving experience for your F150 truck.
Increase in wheel travel over stock
Vehicle specific tuned front shocks for superior shock damping and control
Improved ride quality over stock both on and off-road
Height-adjustable coilovers offer 0-2.
63" of lift height adjustment
ICON engineered coil springs
6061 aircraft grade aluminum CNC machined components
Corrosion resistant CAD plated shock bodies with 7/8" induction hardened, chrome plated shafts
High strength alloy CNC machined lower bar pin
FK Rod End bearings for extended longevity and minimal deflection
100% Bolt-on - no drilling or welding necessary for installation
ICON 2014 Ford F150 2WD, 0-263” Lift, Front 2.
5 VS Coilover Kit, 91615
ICON 2014 Ford F150 2WD, 0-263” Lift, Front 2.
5 VS Coilover Kit.

Detailed Fitment Results
Year Make Model 2014 Ford F-150
