Chevrolet, GMC Coilover Spring and Shock Assembly - Front - ICON Vehicle Dynamics - 71615

COILOVER KIT
71615
Factory Wheels and Tires Fitment: Yes
Recommended Aftermarket Wheels: 17x8.
5" w/ 5.
46” Backspace / 18mm Offset
Recommended Aftermarket Tires: 35" x 12.
50" (Larger Tires May Fit but Fender Trimming and Modifications will be Required)
APPLICATION NOTE #55: Shocks are fully serviceable.
Lift heights indicated are for a stock equipped vehicle.
APPLICATION NOTE #156: Springs are rated for gasoline engines
APPLICATION NOTE #158: Only fits "Ultra-Wide Stance" vehicles
TECH NOTE: Will not fit Chevrolet Colorado WT, LT, or Z71
TECH NOTE: Chevrolet Colorado ZR2 and GMC Canyon AT4X will have front lift height range of.
75"-1.
5" over stock
23-24 GM CANYON/COLORADO 2.
5 VS IR COILOVER KIT
These ICON coilovers feature 2.
5 Series shocks and coil springs optimized for this application.
The shock’s larger 2.
5” body and increased piston area improves damping ability and ride characteristics across varying types of terrain.
ICON Vehicle Dynamics V.
S.
Series 2.
5” coilover shocks are an incredible upgrade for the front-end of 2023-2024 GMC Canyon and 2023-2024 Chevrolet Colorado Trail Boss and Colorado ZR2 trucks.
Their longer length offers an increase in total front wheel travel compared to stock, for a total of 9” front wheel travel while still being compatible with the stock front upper control arms.
ICON’s Vehicle-specific valving provides a sport tuned feel on and off-road while 1.
75-2.
5” of lift height adjustability allows the use of larger, more aggressive wheel and tire combinations.
The larger 2.
5” diameter shock body and increased piston area over stock components provides improved damping ability and outstanding ride characteristics across varying types of terrain.
When paired with ICON rear 2.
0 Aluminum Series or 2.
5 Series shocks vehicle control will be balanced front to rear, resulting in the best overall driving experience for your GMC Canyon or Chevrolet Colorado Trail Boss and ZR2.
Increased front wheel travel and improved ride quality over stock
Vehicle specific tuned for superior shock damping and control
Adjustable for 1.
75-2.
5" of front lift height over stock
Internal nitrogen reservoir ensures consistent performance under hard use
ICON engineered coil springs
Corrosion resistant CAD plated 2.
5” diameter shock bodies
7/8" diameter hardened chrome plated shafts
6061 Aircraft grade aluminum CNC machined components
PTFE lined spherical bearings for extended longevity and minimal deflection
High strength alloy CNC machined lower bar pin and application specific mounting hardware
Fully rebuildable and re-tunable
100% Bolt-on - no drilling, cutting, or welding necessary for installation
ICON 2023-2024 GMC Canyon/Chevrolet Colorado Trail Boss and ZR2, 2.
5 Series Coilover Kit, Internal Reservoir, 71615
ICON 2023-2024 GMC Canyon/Chevrolet Colorado Trail Boss and ZR2, 2.
5 Series Coilover Kit, Internal Reservoir
ICON 23-24 GM CANYON/COLORADO 2.
5 VS IR COILOVER KIT.

Detailed Fitment Results
Year Make Model Submodel 2023 Chevrolet Colorado Trail Boss 2023 Chevrolet Colorado ZR2 2023 GMC Canyon AT4 2023 GMC Canyon Elevation 2023 GMC Canyon Denali 2023 GMC Canyon AT4X 2024 Chevrolet Colorado Trail Boss 2024 Chevrolet Colorado ZR2 2024 GMC Canyon AT4 2024 GMC Canyon Elevation 2024 GMC Canyon Denali 2024 GMC Canyon AT4X
