2023-2025 Ford F-250/F-350 Super Duty 4WD Front 4-Link Conversion Frame Bracket Kit - ICON Vehicle Dynamics - 64053

The 4-link bracket kit is an essential component of the ICON 2023-2025 Ford Super Duty 4-Link Conversion System. This 4-Link system not only gives your Ford Super Duty an aggressive look, it enhances the articulation of the front suspension by eliminating bushing bind and improves handling of the truck by maintaining consistent caster angles through the entirety of the front suspension travel range.

The large, deflective radius arm bushings are replaced with competition grade, PTFE lined spherical bearings in each link. This harder surface minimizes deflection to further increase the overall handling characteristics for maximum predictability and suspension responsiveness.

Additionally, the ICON double adjusters in the lower links allows tuning of caster angle while the links are installed on the vehicle, easing the front-end alignment process.

Features and Benefits:


The 4-link brackets, upper links, and lower links are sold separately, allowing the 4-link system to be customized for your specific Ford Super Duty year range.

4-Link system maintains consistent caster angles through suspension travel for superior handling characteristics

Improves front end articulation and overall drivability

Allows on-vehicle caster adjustment via ICON double adjusters in lower links

Brackets are fabricated from CNC laser cut and brake-formed steel plate

Corrosion resistant semi-gloss black powder coat finish

100 Percent Bolt-on system - no cutting or welding necessary for install

Fabricated components covered under ICON's Limited Lifetime Warranty


Details


Bracket Color: Black

Bracket Material: Steel

Grade: Performance

Grade Type: Performance

Mounting Hardware Included: Yes

Add On Part: 64052 - 23-25 FSD Front Upper Links, 164502 - 05-25 FSD Front Lower Links



Detailed Fitment Results
Year Make Model Engine Fuel 2023 Ford F-350 Super Duty 6.7L DIESEL 2023 Ford F-350 Super Duty 6.8L GAS 2023 Ford F-350 Super Duty 7.3L GAS 2023 Ford F-250 Super Duty 6.7L DIESEL 2023 Ford F-250 Super Duty 6.8L GAS 2023 Ford F-250 Super Duty 7.3L GAS 2024 Ford F-350 Super Duty 6.7L DIESEL 2024 Ford F-350 Super Duty 6.8L GAS 2024 Ford F-350 Super Duty 7.3L GAS 2024 Ford F-250 Super Duty 6.7L DIESEL 2024 Ford F-250 Super Duty 6.8L FLEX 2024 Ford F-250 Super Duty 6.8L GAS 2024 Ford F-250 Super Duty 7.3L GAS 2025 Ford F-350 Super Duty 6.7L DIESEL 2025 Ford F-350 Super Duty 6.8L GAS 2025 Ford F-350 Super Duty 7.3L GAS 2025 Ford F-250 Super Duty 6.7L DIESEL 2025 Ford F-250 Super Duty 6.8L FLEX 2025 Ford F-250 Super Duty 6.8L GAS 2025 Ford F-250 Super Duty 7.3L GAS
