2017-2025 Ford F-250/F-350 Super Duty 4WD Adjustable Track Bar Kit - ICON Vehicle Dynamics - 64038

The ICON Adjustable Track Bar helps center the axle of your lifted 2017-2025 Ford F-250 and F-350 Super Duty and allow for increased suspension travel and articulation. A massive FK Rod End at one end, along with greaseable and replaceable OE style ball joint at the other end yields the best combination of maximum travel and articulation while also removing bushing deflection for improved handling characteristics.

ICON's exclusive rod end Double Adjuster Sleeve allows for fast, easy Inchon-vehicle Inch adjustment of track bar length without requiring removal or disassembly of the track bar. This allows for easy correction of axle location and dialing in precise tracking whenever adjustments are made to ride height.

The track bar is made of CNC bent 1.625 Inch x .250 Inch wall 1026 DOM tubing with CNC machined threaded end and ball joint housing with a multi-stage black powder coat finish. Hit the trail with the confidence of knowing your suspension components are covered by ICON's Limited Lifetime Warranty.

Features and Benefits:


Helps to free up bind during front suspension travel and articulation

Heavy Duty PTFE-lined FK Rod End for maximum articulation and minimal deflection

On-vehicle adjustable for precise track alignment using ICON's double adjuster

Greaseable and replaceable OE style ball joint

CNC machined and bent 1.625 Inch X .250 inch wall 1026 DOM tubing

Multi-stage black powder coat finish for corrosion resistance


Details


Color: Black

Material: Steel

Finish: Powdercoated

Adjustable: Yes

Ball Joint Included: Yes

Bushing Color: Silver

Bushing Material: Rod End Bearing

Bushings Included: No

Dust Boot Included: Yes

End 1 Type: Rod End Bearing

End 2 Type: Ball Joint

Grade Type: Performance

Grease Fitting Included: Yes

Greaseable: Yes

Mounting Hardware Included: Yes

Pre Greased: Yes

Add On Part: 191014 - .25 Inch Collar Spanner Pin Wrench, 64039 - 08-25 FSD Track Bar Bump Steer Bracket Kit



Detailed Fitment Results
Year Make Model Engine Fuel 2017 Ford F-350 Super Duty 6.2L FLEX 2017 Ford F-350 Super Duty 6.7L DIESEL 2017 Ford F-250 Super Duty 6.2L FLEX 2017 Ford F-250 Super Duty 6.7L DIESEL 2018 Ford F-350 Super Duty 6.2L FLEX 2018 Ford F-350 Super Duty 6.7L DIESEL 2018 Ford F-250 Super Duty 6.2L FLEX 2018 Ford F-250 Super Duty 6.7L DIESEL 2019 Ford F-350 Super Duty 6.2L FLEX 2019 Ford F-350 Super Duty 6.7L DIESEL 2019 Ford F-250 Super Duty 6.2L FLEX 2019 Ford F-250 Super Duty 6.7L DIESEL 2020 Ford F-350 Super Duty 6.2L FLEX 2020 Ford F-350 Super Duty 6.7L DIESEL 2020 Ford F-350 Super Duty 7.3L GAS 2020 Ford F-250 Super Duty 6.2L FLEX 2020 Ford F-250 Super Duty 6.7L DIESEL 2020 Ford F-250 Super Duty 7.3L GAS 2021 Ford F-350 Super Duty 6.2L FLEX 2021 Ford F-350 Super Duty 6.7L DIESEL 2021 Ford F-350 Super Duty 7.3L GAS 2021 Ford F-250 Super Duty 6.2L FLEX 2021 Ford F-250 Super Duty 6.7L DIESEL 2021 Ford F-250 Super Duty 7.3L GAS 2022 Ford F-350 Super Duty 6.2L FLEX 2022 Ford F-350 Super Duty 6.7L DIESEL 2022 Ford F-350 Super Duty 7.3L GAS 2022 Ford F-250 Super Duty 6.2L FLEX 2022 Ford F-250 Super Duty 6.7L DIESEL 2022 Ford F-250 Super Duty 7.3L GAS 2023 Ford F-350 Super Duty 6.7L DIESEL 2023 Ford F-350 Super Duty 6.8L GAS 2023 Ford F-350 Super Duty 7.3L GAS 2023 Ford F-250 Super Duty 6.7L DIESEL 2023 Ford F-250 Super Duty 6.8L GAS 2023 Ford F-250 Super Duty 7.3L GAS 2024 Ford F-350 Super Duty 6.7L DIESEL 2024 Ford F-350 Super Duty 6.8L GAS 2024 Ford F-350 Super Duty 7.3L GAS 2024 Ford F-250 Super Duty 6.7L DIESEL 2024 Ford F-250 Super Duty 6.8L FLEX 2024 Ford F-250 Super Duty 6.8L GAS 2024 Ford F-250 Super Duty 7.3L GAS 2025 Ford F-350 Super Duty 6.7L DIESEL 2025 Ford F-350 Super Duty 6.8L GAS 2025 Ford F-350 Super Duty 7.3L GAS 2025 Ford F-250 Super Duty 6.7L DIESEL 2025 Ford F-250 Super Duty 6.8L FLEX 2025 Ford F-250 Super Duty 6.8L GAS 2025 Ford F-250 Super Duty 7.3L GAS
