Ford (4WD) Coilover Spring and Shock Assembly - Front - ICON Vehicle Dynamics - 61721C

FSD COILOVER KIT
61721C
Factory Wheels and Tires Fitment: Yes
Recommended Aftermarket Wheels: ICON Alloys - 17x8.
5" w/ 5.
00” Backspace / 6mm Offset
Recommended Aftermarket Wheels: ICON Alloys - 18x9" w/ 5.
25” Backspace / 6mm Offset
Recommended Aftermarket Wheels: ICON Alloys - 20x9" w/ 5.
25” Backspace / 6mm Offset
Recommended Aftermarket Tires (2005-2016 models): 35" x 12.
50" (37" x 12.
50" with fender trimming and modifications required)
Recommended Aftermarket Tires (2017-2024 models): 37" x 12.
50" (Larger tires may fit but fender trimming and modifications will be required)
TECH NOTE: Only compatible with 4WD models
TECH NOTE: Not compatible with F-450 or F-550
TECH NOTE: Removal of the coil centering cup in factory coil bucket required for installation
TECH NOTE: 2005-2019 Super Duty diesel models will have front lift height range of 4-5.
5" over stock
TECH NOTE: 2020-2022 Super Duty diesel models without Tremor package will have front lift height range of 4.
75-6.
25" over stock
TECH NOTE: 2020-2022 Super Duty diesel models equipped with Tremor package will have front lift height range of 3.
75-5.
25" over stock
TECH NOTE: 2023-2024 Super Duty diesel models without Tremor package will have front lift height range of 4-5.
5" over stock
TECH NOTE: 2023-2024 Super Duty diesel models equipped with Tremor package will have front lift height range of 3-4.
5" over stock
TECH NOTE: 2023-2024 Super Duty gas models without Tremor package will have front lift height range of 4.
5-6" over stock
TECH NOTE: 2023-2024 Super Duty gas models equipped with Tremor package will have front lift height range of 3.
5-5" over stock
TECH NOTE: If installing with ICON 2.
5 Series remote reservoir secondary shocks, reservoir doubler kit part number 611003 is also required
05-24 FSD 4WD 4-5.
5" 2.
5 VS RR CDCV BOLT IN CO CONVERSION KIT
ICON's 2.
5 Series Bolt-In Coilover Conversion Kit will add a new level of performance and adjustability to Ford Super Duty trucks.
They have been designed to increase the overall damping ability while also allowing ride height adjustment.
ICON's 2.
5 VS Series Remote Reservoir Bolt-In Coilover Conversion Kit will add a new level of performance and adjustability to 2005-2024 F-250 and F-350 Super Duty pickup trucks.
The advantage of utilizing a coilover conversion kit is that they have been designed to increase the overall damping ability of the vehicle while at the same time allowing for user-defined ride height adjustment.
The 2.
5" Remote Reservoir Coilover featured in these kits is based off of ICON’s 2.
5 VS Series shock line - meaning that features like ICON engineered coil springs, FK Rod End bearings, and vehicle-specific valving come standard.
Quality machined components and a fully serviceable design make for a product that will stand the test of time, yet retain the ability to be rebuilt or re-valved as necessary.
ICON's exclusive Compression Damping Control Valves ICON’s CDC (Compression Damping Control) Valve option adds to the adjustability of these coilover conversion kits, allowing the end-user to adjust the ride characteristics of the vehicle with the turn of a knob.
CDCV controls fluid flow under compression, allowing you to achieve the perfect tune whether driving on the street, slow-crawling through the rocks or mobbing across the desert at full throttle.
Bolt-in system fits in OE coil bucket location
Ride height adjustable coilovers for 4-5.
5” of front lift over stock
Decreased body roll and improved on and off-road ride dynamics
Vehicle-specific shock valving provides unparalleled ride quality and control
ICON CDCV equipped for 10 settings of external compression damping adjustment
Shocks are fully rebuildable and revalveable
Coilover conversion allows for addition of secondary shock
Corrosion resistant CAD plated coilover shock bodies with 7/8" shafts
ICON engineered coil springs guaranteed for life against sagging or breakage
FK Rod End bearings for extended longevity and minimal deflection
ICON 2005-2024 Ford F-250/F-350 Super Duty 4WD, 4-5.
5” Lift, Front, 2.
5 V.
S.
Remote Reservoir CDCV Coilover Conversion Kit, 61721C
ICON 2005-2024 Ford F-250/F-350 Super Duty 4WD, 4-5.
5” Lift, Front, 2.
5 V.
S.
Remote Reservoir CDCV Coilover Conversion Kit
ICON 05-24 FSD 4WD 4-5.
5" 2.
5 VS RR CDCV BOLT IN CO CONVERSION KIT.

Detailed Fitment Results
Year Make Model Submodel Qualifiers Fitment Notes 2005 Ford F-250 Super Duty 2005 Ford F-350 Super Duty 2006 Ford F-250 Super Duty 2006 Ford F-350 Super Duty 2007 Ford F-250 Super Duty 2007 Ford F-350 Super Duty 2008 Ford F-250 Super Duty 2008 Ford F-350 Super Duty 2009 Ford F-250 Super Duty 2009 Ford F-350 Super Duty 2010 Ford F-250 Super Duty 2010 Ford F-350 Super Duty 2011 Ford F-250 Super Duty 2011 Ford F-350 Super Duty 2012 Ford F-250 Super Duty 2012 Ford F-350 Super Duty 2013 Ford F-250 Super Duty 2013 Ford F-350 Super Duty 2014 Ford F-250 Super Duty 2014 Ford F-350 Super Duty 2015 Ford F-250 Super Duty 2015 Ford F-350 Super Duty 2016 Ford F-250 Super Duty 2016 Ford F-350 Super Duty 2017 Ford F-250 Super Duty 2017 Ford F-350 Super Duty 2018 Ford F-250 Super Duty 2018 Ford F-350 Super Duty 2019 Ford F-250 Super Duty 2019 Ford F-350 Super Duty 2020 Ford F-250 Super Duty XL 2020 Ford F-250 Super Duty Lariat 2020 Ford F-250 Super Duty King Ranch 2020 Ford F-250 Super Duty Platinum 2020 Ford F-250 Super Duty Limited 2020 Ford F-250 Super Duty XLT 2020 Ford F-350 Super Duty XL 2020 Ford F-350 Super Duty XLT 2020 Ford F-350 Super Duty Lariat 2020 Ford F-350 Super Duty King Ranch 2020 Ford F-350 Super Duty Platinum 2020 Ford F-350 Super Duty Limited 2021 Ford F-250 Super Duty XL 2021 Ford F-250 Super Duty Lariat 2021 Ford F-250 Super Duty King Ranch 2021 Ford F-250 Super Duty Platinum 2021 Ford F-250 Super Duty Limited 2021 Ford F-250 Super Duty XLT 2021 Ford F-350 Super Duty XL 2021 Ford F-350 Super Duty XLT 2021 Ford F-350 Super Duty Lariat 2021 Ford F-350 Super Duty K…
