10-24 Toyota 4Runner Suspension Shock Absorber Set - Rear - ICON Vehicle Dynamics - 57810EP

SHOCK ABSORBER PAIR
57810EP
TECH NOTE: Also requires installation of IIC kit (Part # 53504) and CDEV front coilovers (Part # 58747E)
TECH NOTE: Compatible with 1-3" of rear lift over stock
TECH NOTE: Only compatible with models equipped with 4.
0L V6 engine
TECH NOTE: Vehicles equipped with Kinetic Dynamic Suspension System (KDSS) also require ICON rear track bar part numer 54200
10-24 4RUNNER 1-3" REAR 2.
5 VS RR CDEV PAIR
ICON VS 2.
5 Aluminum Series shocks are designed and built to give your vehicle outstanding performance off-road and a smooth ride on the street.
They feature remote reservoirs with CDEV and are 100% rebuildable/revalveable.
ICON Vehicle Specific (V.
S.
) 2.
5 Aluminum Series shocks with CDEV are designed and built to give your vehicle outstanding performance off-road and a smooth ride on the street.
These shocks are configured specifically for each application in both length and damping tune.
For piggyback and specific remote reservoir applications, ICON'S unique use of a 6061 billet aluminum manifold a few inches below the top cap of the shock creates an internal Bump Zone that when used creates an additional 20% of damping force.
This additional force helps prevent harsh bottom outs and controls the suspension when compressing at high velocity.
Like all ICON'S Shock Absorbers, V.
S.
2.
5 Aluminum Series shocks with CDEV are 100% rebuildable and 100% revalveable.
Compression Damping Electronic Valve (CDEV) is an electronically controlled valve that meters the flow of oil to regulate the amount of damping force that is created by the shock when compressed.
This infinitely variable valve can react in less than 40ms and has the ability to make extremely precise adjustments for varying terrain.
CDEV’s hydraulic circuits are also custom tailored per application to create the highest resolution and dynamic range allowable for each specific vehicle.
Powered by ICON Intelligent Control and proprietary ICON mobile app, the system uses information from the onboard G-force sensor and Gyroscope to perform calculations based on algorithms and user-defined settings to predict terrain and adjust shock settings via the CDEV accordingly.
ICON's CDE Valve technology allows for in vehicle adjustment of compression damping settings and active adjustment via the ICON Intelligent Control (IIC)
ICON’s internal “Bump Zone” increases damping by 20% to provide more control as the shock approaches full compression
One-piece, hard anodized, impact extruded aluminum cylinders offer excellent corrosion resistance and consistent finish
Remote reservoir design improves heat dissipation to reduce shock fade during prolonged use
Premium grade 5WT shock oil for consistent suspension damping along a wide temperature range
Nitrogen charged monotube design with piggyback reservoir
One-piece digressive piston design with vehicle specific valving for unsurpassed performance and ride quality on and off-road
7/8” diameter induction hardened, chrome plated shock shaft
PTFE lined spherical bearings and application specific mounting hardware
6061 aircraft grade aluminum CNC machined components
100% Rebuildable
100% Revalveable
ICON 2010-2024 Toyota 4Runner, 1-3” Lift, Rear V.
S.
2.
5 Aluminum Series Shocks, Remote Reservoir w/ CDEV, Pair, 57810EP
ICON 2010-2024 Toyota 4Runner, 1-3” Lift, Rear V.
S.
2.
5 Aluminum Series Shocks, Remote Reservoir w/ CDEV, Pair
ICON 10-24 4RUNNER 1-3" REAR 2.
5 VS RR CDEV PAIR.

Detailed Fitment Results
Year Make Model Submodel 2010 Toyota 4Runner Limited 2010 Toyota 4Runner SR5 2010 Toyota 4Runner Trail 2011 Toyota 4Runner Limited 2011 Toyota 4Runner SR5 2011 Toyota 4Runner Trail 2012 Toyota 4Runner Limited 2012 Toyota 4Runner SR5 2012 Toyota 4Runner Trail 2013 Toyota 4Runner Limited 2013 Toyota 4Runner SR5 2013 Toyota 4Runner Trail 2014 Toyota 4Runner Limited 2014 Toyota 4Runner SR5 2014 Toyota 4Runner Trail 2015 Toyota 4Runner Limited 2015 Toyota 4Runner SR5 2015 Toyota 4Runner Trail 2015 Toyota 4Runner TRD Pro 2016 Toyota 4Runner Limited 2016 Toyota 4Runner SR5 2016 Toyota 4Runner Trail 2016 Toyota 4Runner TRD Pro 2017 Toyota 4Runner Limited 2017 Toyota 4Runner SR5 2017 Toyota 4Runner TRD Pro 2017 Toyota 4Runner TRD Off-Road 2017 Toyota 4Runner Base 2018 Toyota 4Runner Limited 2018 Toyota 4Runner SR5 2018 Toyota 4Runner TRD Pro 2018 Toyota 4Runner TRD Off-Road 2018 Toyota 4Runner Base 2018 Toyota 4Runner SR5 Premium 2018 Toyota 4Runner TRD Off-Road Premium 2019 Toyota 4Runner Limited 2019 Toyota 4Runner SR5 2019 Toyota 4Runner TRD Pro 2019 Toyota 4Runner TRD Off-Road 2019 Toyota 4Runner SR5 Premium 2019 Toyota 4Runner TRD Off-Road Premium 2020 Toyota 4Runner Limited 2020 Toyota 4Runner SR5 2020 Toyota 4Runner TRD Pro 2020 Toyota 4Runner TRD Off-Road 2020 Toyota 4Runner Base 2020 Toyota 4Runner SR5 Premium 2020 Toyota 4Runner TRD Off-Road Premium 2020 Toyota 4Runner Nightshade 2020 Toyota 4Runner Venture 2021 Toyota 4Runner Limited 2021 Toyota 4Runner SR5 2021 Toyota 4Runner TRD Pro 2021 Toyota 4Runner TRD Off-Road 2021 Toyota 4Runner Base 2021 Toyota 4Runner SR5 Premium 2021 Toyota 4Runner TRD Off-Road Premium 2021 Toyota 4Runner Nightshade 2021 Toyota 4Runner Venture 2021 Toyota 4Runner Trail 2022 Toyota 4Runner Limited 2022 Toyota 4Runner SR5 2022 Toyota 4Runner TRD Pro 2022 Toyota 4Runner TRD Off-Road 2022 Toyota 4Runner SR5 Premium 2022 Toyota 4Runner TRD Off-Road Premium 2022 Toyota 4Runner Nightshade 2022 Toyota 4Runner Venture 2022 Toyota 4Runner Trail 2022 Toyota 4Runner TRD Sport 2023 Toyota 4Runner Limited 2023 Toyota 4Runner SR5 2023 Toyota 4Runner TRD Pro 2023 Toyota 4Runner TRD Off-Road 2023 Toyota 4Runner SR5 Premium 2023 Toyota 4Runner TRD Off-Road Premium 2023 Toyota 4Runner TRD Sport 2023 Toyota 4Runner 40th Anniversary Edition 2024 Toyota 4Runner Limited 2024 Toyota 4Runner SR5 2024 Toyota 4Runner TRD Pro 2024 Toyota 4Runner TRD Off-Road 2024 Toyota 4Runner SR5 Premium 2024 Toyota 4Runner TRD Off-Road Premium 2024 Toyota 4Runner …
