Lexus, Toyota (Coil/Air) Suspension Control Arm Kit - ICON Vehicle Dynamics - 54102T

REAR UPPER LINK KIT
54102T
APPLICATION NOTE #141: Tundra/Sequoia equipped with Automatic Leveling Headlights or Load-Leveling Rear Height Control Air Suspension part # 55153 is also required
APPLICATION NOTE #143: Compatible with ICON Tundra 6" Lift Performance Suspension System but may not be compatible with 6" lift kits from other manufacturers
APPLICATION NOTE #164: Will not fit Tacoma submodels equipped with rear leaf springs
APPLICATION NOTE #199: Land Cruiser 250 Series and GX550 also require Sensor Bracket part number 55161
22-25 TUNDRA/23-25 SEQUOIA/24-25 TACOMA/24 LC250/GX550 TUBE REAR UPPER LINK KIT
The ICON Tubular Rear Upper Link System helps free up rear axle movement to allow for increased suspension travel and articulation.
Formed using DOM steel tubing for high strength, with CNC machined threaded ends and bushing housings.
The ICON Tubular Rear Upper Link System helps free up rear axle movement on the 2022-2025 Toyota Tundra, 2023-2025 Toyota Sequoia, 2024-2025 Toyota Tacoma, 2024 Toyota Land Cruiser 250 Series, and the 2024 Lexus GX550 to allow for increased suspension travel and articulation.
Formed using 1 ¾” x.
313 wall DOM Tubing for high strength, with CNC machined threaded ends and bushing housings, and feature a multi-stage black powder coat finish.
These upper links are designed with massive FK Rod End at one end, along with a dual-durometer, high angle greaseless bushing at the other end yields the best combination of maximum travel and articulation while isolating and damping road noise and vibrations.
The quality rod ends and bushings featured in these link arms allow the vehicle’s suspension to function as intended, without the bushing bind that limits the vehicle in stock form.
Hit the trail with the confidence of knowing your suspension components are covered by ICON’s Limited Lifetime Warranty.
Adjustable for various lift heights and driveline angles
Help free rear suspension bind compared to OE links
CNC machined and notched 1026 DOM steel construction with semi-gloss black powder coat finish
Multi durometer bushings for noise free operation and maximum angularity
No grease required for life of bushings
Quality JM16T PTFE-lined FK Rod Ends
Fabricated components covered under ICON's Limited Lifetime Warranty
ICON 2022-2025 Toyota Tundra/2023-2025 Toyota Sequoia/2024-2025 Toyota Tacoma/2024 Toyota Land Cruiser 250 Series/2024 Lexus GX550, Rear, Tubular Upper Link Kit, 54102T
ICON 2022-2025 Toyota Tundra/2023-2025 Toyota Sequoia/2024-2025 Toyota Tacoma/2024 Toyota Land Cruiser 250 Series/2024 Lexus GX550, Rear, Tubular Upper Link Kit
ICON 22-25 TUNDRA/23-25 SEQUOIA/24-25 TACOMA/24 LC250/GX550 TUBE REAR UPPER LINK KIT.

Detailed Fitment Results
Year Make Model Submodel Qualifiers Fitment Notes 2022 Toyota Tundra Limited 2022 Toyota Tundra SR ; May not be compatible with other manufacturer’s 6 inch lift kits; 2022 Toyota Tundra TRD Pro 2022 Toyota Tundra Capstone May not be compatible with other manufacturer’s 6 inch lift kits 2022 Toyota Tundra Platinum 2022 Toyota Tundra SR5 2022 Toyota Tundra 1794 Edition 2022 Toyota Tundra Platinum 1794 Edition May not be compatible with other manufacturer’s 6 inch lift kits 2022 Toyota Tundra SR TRD Off-Road May not be compatible with other manufacturer’s 6 inch lift kits 2022 Toyota Tundra SR5 TRD Off-Road 2022 Toyota Tundra Limited TRD Off-Road 2023 Toyota Tundra Limited 2023 Toyota Tundra SR ; May not be compatible with other manufacturer’s 6 inch lift kits; 2023 Toyota Tundra TRD Pro 2023 Toyota Tundra Capstone May not be compatible with other manufacturer’s 6 inch lift kits 2023 Toyota Tundra Platinum 2023 Toyota Tundra SR5 2023 Toyota Tundra 1794 Edition 2023 Toyota Sequoia Capstone 2023 Toyota Sequoia Limited 2023 Toyota Sequoia Platinum 2023 Toyota Sequoia SR5 2023 Toyota Sequoia TRD Pro 2023 Toyota Sequoia TRD Off-Road 2024 Lexus GX550 2024 Toyota Land Cruiser 2024 Toyota Tundra Limited 2024 Toyota Tundra SR ; May not be compatible with other manufacturer’s 6 inch lift kits; 2024 Toyota Tundra TRD Pro 2024 Toyota Tundra Capstone May not be compatible with other manufacturer’s 6 inch lift kits 2024 Toyota Tundra Platinum 2024 Toyota Tundra SR5 2024 Toyota Tundra 1794 Edition 2024 Toyota Sequoia Capstone 2024 Toyota Sequoia Limited 2024 Toyota Sequoia Platinum 2024 Toyota Sequoia SR5 2024 Toyota Sequoia TRD Pro 2024 Toyota Tacoma SR5 2024 Toyota Tacoma TRD Off-Road 2024 Toyota Tacoma Limited 2024 Toyota Tacoma TRD Sport 2025 Toyota Tundra Limited 2025 Toyota Tundra SR ; May not be compatible with other manufacturer’s 6 inch lift kits; 2025 Toyota Tundra TRD Pro 2025 Toyota Tundra Capstone May not be compatible with other manufacturer’s 6 inch lift kits 2025 Toyota Tundra Platinum 2025 Toyota Tundra SR5 2025 Toyota Tundra 1794 Edition 2025 Toyota Tundra TRD Off-Road 2025 Toyota Sequoia Capstone 2025 Toyota Sequoia Limited 2025 Toyota Sequoia Platinum 2025 Toyota Sequoia SR5 2025 Toyota Sequoia TRD Pro 2025 Toyota Sequoia 1794 Edition 2025 Toyota Tacoma SR5 2025 Toyota Tacoma TRD Off-Road 2025 Toyota Tacoma Limited 2025 Toyota Tacoma TRD Sport Premium 2025 Toyota Tacoma TRD Sport
