Lexus, Toyota (Air/Coil) Suspension Control Arm Kit - ICON Vehicle Dynamics - 54102G

REAR UPPER LINK KIT
54102G
APPLICATION NOTE #141: Tundra/Sequoia equipped with Automatic Leveling Headlights or Load-Leveling Rear Height Control Air Suspension part # 55153 is also required
APPLICATION NOTE #143: Compatible with ICON Tundra 6" Lift Performance Suspension System but may not be compatible with 6" lift kits from other manufacturers
APPLICATION NOTE #164: Will not fit Tacoma submodels equipped with rear leaf springs
APPLICATION NOTE #199: Land Cruiser 250 Series and GX550 also require Sensor Bracket part number 55161
22-25 TUNDRA/23-25 SEQUOIA/24-25 TACOMA/24 LC250/GX550 BLT REAR UPR LINKS GOLD
ICON billet trailing arms are light, strong, and engineered to improve off-road ride quality.
Built with CNC machined 6061 aluminum, they feature PTFE-lined rod ends, replaceable nylon rock sliders for protection, and on-vehicle adjustment.
ICON’s billet aluminum rear upper link arms for the 2022-2025 Toyota Tundra, 2023-2025 Toyota Sequoia, 2024-2025 Toyota Tacoma, 2024 Toyota Land Cruiser 250 Series, and 2024 Lexus GX550 are a significant upgrade over the factory units due to increases in strength, adjustability, and performance.
These links are made from CNC machined 6061 aluminum in-house and anodized for corrosion resistance, providing a major improvement over the construction of the stock units.
An all-new gold anodized finish matches ICON shock absorbers for a splash of color in the wheel well and provide a custom look to any build.
This rear upper link arm kit features PTFE-lined FK rod ends for increased suspension articulation, reduced deflection, and on-vehicle link arm length adjustability using ICON’s double adjuster system.
Additionally, multi durometer bushings are installed that allow for noise free operation and maximum angularity without the need for periodic greasing and/or other maintenance.
The quality rod ends and bushings featured in these link arms allow the vehicle’s suspension to function as intended, without the bushing bind that limits the vehicle in stock form.
After the design phase was completed ICON engineers put these parts through the “ICON1K” real-world test cycle for a final stamp of approval.
Vehicle specific design
On vehicle adjustment for different ride heights and pinion angles using ICON's Double Adjuster System
CNC machined 6061 aluminum construction
Gold anodized finish
Large FK Bearing JMX16T PTFE-lined rod ends
Maintenance free, dual durometer bushings for maximum angularity and noise isolation
Covered by ICON’s Limited Lifetime Warranty
ICON 2022-2025 Toyota Tundra/2023-2025 Toyota Sequoia/2024-2025 Toyota Tacoma/2024 Toyota Land Cruiser 250 Series/2024 Lexus GX550, Rear, Billet Upper Link Kit, Gold Anodizing, 54102G
ICON 2022-2025 Toyota Tundra/2023-2025 Toyota Sequoia/2024-2025 Toyota Tacoma/2024 Toyota Land Cruiser 250 Series/2024 Lexus GX550, Rear, Billet Upper Link Kit, Gold Anodizing
ICON 22-25 TUNDRA/23-25 SEQUOIA/24-25 TACOMA/24 LC250/GX550 BLT REAR UPR LINKS GOLD.

Detailed Fitment Results
Year Make Model Submodel 2022 Toyota Tundra SR5 2022 Toyota Tundra Limited 2022 Toyota Tundra SR 2022 Toyota Tundra TRD Pro 2022 Toyota Tundra Capstone 2022 Toyota Tundra Platinum 2022 Toyota Tundra 1794 Edition 2022 Toyota Tundra Platinum 1794 Edition 2022 Toyota Tundra SR TRD Off-Road 2022 Toyota Tundra SR5 TRD Off-Road 2022 Toyota Tundra Limited TRD Off-Road 2023 Toyota Tundra SR5 2023 Toyota Tundra Limited 2023 Toyota Tundra SR 2023 Toyota Tundra TRD Pro 2023 Toyota Tundra Capstone 2023 Toyota Tundra Platinum 2023 Toyota Tundra 1794 Edition 2023 Toyota Sequoia Capstone 2023 Toyota Sequoia Limited 2023 Toyota Sequoia Platinum 2023 Toyota Sequoia SR5 2023 Toyota Sequoia TRD Pro 2023 Toyota Sequoia TRD Off-Road 2024 Lexus GX550 2024 Toyota Land Cruiser 2024 Toyota Tundra SR5 2024 Toyota Tundra Limited 2024 Toyota Tundra SR 2024 Toyota Tundra TRD Pro 2024 Toyota Tundra Capstone 2024 Toyota Tundra Platinum 2024 Toyota Tundra 1794 Edition 2024 Toyota Sequoia Capstone 2024 Toyota Sequoia Limited 2024 Toyota Sequoia Platinum 2024 Toyota Sequoia SR5 2024 Toyota Sequoia TRD Pro 2024 Toyota Tacoma SR5 2024 Toyota Tacoma TRD Off-Road 2024 Toyota Tacoma Limited 2024 Toyota Tacoma TRD Sport 2025 Toyota Tundra SR5 2025 Toyota Tundra Limited 2025 Toyota Tundra SR 2025 Toyota Tundra TRD Pro 2025 Toyota Tundra Capstone 2025 Toyota Tundra Platinum 2025 Toyota Tundra 1794 Edition 2025 Toyota Tundra TRD Off-Road 2025 Toyota Sequoia Capstone 2025 Toyota Sequoia Limited 2025 Toyota Sequoia Platinum 2025 Toyota Sequoia SR5 2025 Toyota Sequoia TRD Pro 2025 Toyota Sequoia 1794 Edition 2025 Toyota Tacoma SR5 2025 Toyota Tacoma TRD Off-Road 2025 Toyota Tacoma Limited 2025 Toyota Tacoma TRD Sport Premium 2025 Toyota Tacoma TRD Sport
