Cast Aluminum Rear Sump Oil Pan - Ford Coyote Swap - Holley - 302-47

Holley's new Gen1/Gen2 Coyote oil pan makes your Ford Fox-Body Mustang swap easier. The oil pan design provides a healthy oil capacity of of 9.0 quarts (9.5 w/ stock filter) to ensure adequate oil supply in all street performance and factory-stock type racing applications. The new design installs using stock Coyote engine gasket/baffle assembly to provide factory-like sealing and baffling/windage characteristics. A proprietary design pick-up tube/O-ring and lower sump baffle plate are included as well as two drain-back bosses (unmachined) for turbo applications or catch can returns. - The 302-47 was specifically designed to enable Coyote Gen 1 and 2 engine swaps in 1979-2004 Ford Fox-Body Mustangsusing a stock (1984-2004), AJE MU40-UM, Team Z Motorsports TZM-KM-SWAP, or Maximum Motorsports MMKM-2.1 (for Fox Body cars) or MMKM 2 (for SN95/New Edge cars) K-member and Hooker Blackheart engine mounting brackets. This pan is not compatible with the Maximum Motorsports MMKM-1 K-member. - The unique fitment geometry of this pan may also be suitable for use in other fitment challenged Coyote swap applications. - ***You may need to make a custom tool from an inexpensive 1/4" drive 10mm deep socket to torque the outer bolt of the pick-up tube assembly flange to the oil pump. Image included in instructions.
Provides 9 qts of oil capacity to ensure adequate oil supply in all street performance and factory-stock type racing applications. - Oil pan fits 2011-2017 Gen I and II Coyote engines and provides more header, steering rack, and intake manifold clearance than other Coyote oil pans. - Provides compatibility with OE Fox-Body/SN95 Mustang clutch release cables - Installs using stock Coyote engine gasket/baffle assembly to provide factory-like sealing and baffling/windage characteristics. - Provides compatibility with the stock Gen 1 and 2 Mustang Coyote engine low-oil level sensor - Proprietary design pick-up tube/O-ring and lower sump baffle plate are included. - Provides 2 Bosses for drain-back for turbo applications (Unmachined) - Traditional high-quality cast aluminum appearance with clean exterior styling
part type: Engine Oil Pan | Brand: Holley | Material: Cast Aluminum | Finish: Natural Cast

Detailed Fitment Results
Year Make Model Engine Size Sub Model Fitment Notes 1900 5 1900 5.2 1979 Ford Mustang Base / Ghia Coyote Swap 1979 Mercury Capri Base / Ghia Coyote Swap 1980 Ford Mustang Base / Ghia Coyote Swap 1980 Mercury Capri Base / Ghia Coyote Swap 1981 Ford Mustang Base / Ghia / Cobra Coyote Swap 1981 Mercury Capri Base / GS Coyote Swap 1982 Ford Mustang Base / Ghia / GT / L / GL / GLX Coyote Swap 1982 Mercury Capri Base / GS / RS / L / Black Magic Coyote Swap 1983 Ford Mustang Base / GT / L / GL / GLX / Turbo GT Coyote Swap 1983 Mercury Capri Base / GS / RS / L / Black Magic / Crimson Cat Coyote Swap 1984 Ford Mustang Base / GT / L / LX / SVO / GT-350 20th Anniversary Coyote Swap 1984 Mercury Capri GS / RS / RS Turbo Coyote Swap 1985 Ford Mustang GT / LX / SVO Coyote Swap 1985 Mercury Capri GS / RS Coyote Swap 1986 Ford Mustang GT / LX / SVO Coyote Swap 1986 Mercury Capri GS / 5.0 Coyote Swap 1987 Ford Mustang GT / LX Coyote Swap 1988 Ford Mustang GT / LX Coyote Swap 1989 Ford Mustang GT / LX Coyote Swap 1990 Ford Mustang GT / LX Coyote Swap 1991 Ford Mustang GT / LX Coyote Swap 1992 Ford Mustang GT / LX Coyote Swap 1993 Ford Mustang GT / LX / SVT Cobra / SVT Cobra R Coyote Swap 1994 Ford Mustang Base / GT / SVT Cobra Coyote Swap 1995 Ford Mustang Base / GT / SVT Cobra / SVT Cobra R / GTS Coyote Swap 1996 Ford Mustang Base / GT / SVT Cobra / High Coyote Swap 1997 Ford Mustang Base / Cobra / GT / SVT Cobra / High Coyote Swap 1998 Ford Mustang Base / GT / SVT Cobra / Equipado / Semi-Equipado Coyote Swap 1999 Ford Mustang Base / GT / SVT Cobra / Equipado Coyote Swap 2000 Ford Mustang Base / GT / SVT Cobra R / Equipado Coyote Swap 2001 Ford Mustang Base / GT / SVT Cobra / Equipado / GT Bullitt Coyote Swap 2002 Ford Mustang Base / GT / Equipado Coyote Swap 2003 Ford Mustang Base / GT / SVT Cobra / Equipado / Mach 1 / SVT Cobra 10th Anniversary Coyote Swap 2004 Ford Mustang Base / GT / SVT Cobra / Mach 1 / GT Equipado / GT Base Coyote Swap
