Carb/efi Adjustable Billet By-Pass Regulator-6AN Kit Carb/efi Adjustable Billet By-Pass Return Style Fuel Pressure Regulator 6AN Kit with Fuel Pressure Gauge and Adapter Fittings Boost Reference 11 - Holley - 12-880KIT

Holley Billet Fuel Pressure Regulators are part of a complete line of fuel system products from Holley. They are precision machined from 6061-T6 billet aluminum for strength and durability.

These regulators are adjustable from 4-65 psi and will handle both carbureted and EFI applications. A second pressure spring is included allowing you to increase the fuel pressure range up to 65 psi for EFI systems.

They have 6AN port sizes to adapt to your new or existing fuel lines. So, if you are currently running a carbureted system but plan to upgrade to EFI in the future, these regulators will have you covered either way.

These kits include a fuel pressure gauge and adapter fittings to get you started on your installation.

Adjustable from 4-65 psi for precise fuel pressure adjustments Constructed of billet aluminum with a black anodized base and a clear anodized top for good looks Used in systems with a return line back to the tank (1) 6AN O-ring Inlet

Features and Benefits:


(1) 6AN O-ring Outlet

and (1) 6AN O-ring return Includes fitting for manifold reference Includes an 1/8 NPT gauge port Boost Reference - 1:1 The 4-15 psi carbureted spring comes installed in the regulator


Details:


Adjustable: Yes

Color: Black

Fuel Type: Gasoline

Fuel System: EFI/Carb

Gauge Port: Yes

Grade Type: Performance

Inlet Quantity: 1

Inlet Size: 6 An O-Ring

Inlet Type: 6 An Orb

Material: Aluminum

Mounting Hardware Included: Yes

Mounting Type: Inline

Outlet Quantity: 1

Outlet Size: 6 An O-Ring

Outlet Type: 6 An Orb

Port Quantity: 3.0

Return Size: 6 An O-Ring

Style: Bypass

Warranty: Manufacturer's Limited 90 Day Warranty
