Ford (4WD) Suspension Lift Kit - Carli Suspension - CS-FLVL-BC-CS-23

Backcountry Leveling
CS-FLVL-BC-CS-23
Required and Optional Parts to support this system:
Sway Bar Options (REQUIRED): CS-FSBD-LVL-1723 or CS-FEL-LVL-17 or CS-FTSB-LVL-17
Radius Arms: CS-FARA-LVL-23
Leaf Spring Options (REQUIRED): CS-FPAP-LVL-17 or CS-FFSP-LVL-17 or CS-FFSP-LVL-17-HD
Leaf Spring Shackle: CS-FSHACKLE-11
Steering Stabilizer - High mount: CS-FHMSS-17
Steering Stabilizer - Low mount: CS-FLMSS-23
Trophy Hitch: CS-FHITCH-1723
Back country, super duty
Carli Backcountry Leveling Suspension, 3.5” Lift, 2023+ Ford F250/F350
23+ FORD F250/350 4X4 DIESEL 3.5" LIFT BACKCOUNTRY SYSTEM
The Backcountry System is made for those seeking the best ride on and off-road without breaking the bank; You’re no longer limited to the highway while gravel roads become dull as you can drive them at speed with one hand on the wheel.
Carli’s Backcountry 2.0 system delivers a keen balance of on-road stability and mild off-road ability for a reasonable price. The base system touches all critical components, addressing wheel travel, proper geometry, smoothness, and durability while delivering an aggressive level stance. The kit is based on Carli-Spec 2.0-inch diameter remote reservoir shocks. Carli engineers developed a valving tune that addresses on-road, in-town, highway driving, towing and/or hauling, as well as slow- to medium-speed off-road use. The shocks boast 6063 aluminum construction, fully anodized body for corrosion resistance, 5/8″ hardened steel chrome plated shock shaft, a fully serviceable/rebuildable design, and 6061-billet rod-ends with one-piece bushings. This suspension transforms your truck into a rig that is smoother than stock on the highway but has the moxie to tackle mild trail running and off-roading with ease.
Features Carli-Tuned remote reservoir 2.0 shocks which provide a more comfortable on-road feel and better off-road performance. Corrosion resistant aluminum bodies provide long-lasting finish.
System includes linear rate coil springs, front and rear shock package, brake line kit, bump stop drops, caster correction shims, radius arm drop brackets, and adjustable track bar.
Fits up to 37" tires with ease for a more aggresize appearance and better offroad performance.
Increases wheel travel to 9" front and 13.8" rear.
Parts Included: AS-FLVLSPKG-CS20RR-A; CS-FATB-17; CS-FBDF-25-17; CS-FCASTERSHIM-45; CS-FLC-05; CS-FORDBBL-LVL-17-F; CS-FRM-20; CS-FRAD-LVL-2325
Features Carli-Tuned remote reservoir 2.0 shocks which provide a more comfortable on-road feel and better off-road performance. Corrosion resistant aluminum bodies provide long-lasting finish.
System includes linear rate coil springs, front and rear shock package, brake line kit, bump stop drops, caster correction shims, radius arm drop brackets, and adjustable track bar.
Fits up to 37" tires with ease for a more aggresize appearance and better offroad performance.
Increases wheel travel to 9" front and 13.8" rear.
California Proposition 65: WARNING: This product can expose you to chemicals including arsenic, which is known to the State of California to cause cancer. For more information, go to www.P65Warnings.ca.gov.
Coils Quantity Front: 2
Maximum Lift: 3.5
Shocks Included: Yes
Spring Color: Black
Spring Material: Steel

Detailed Fitment Results
Year Make Model Drive Type 2023 Ford F-250 Super Duty 4WD 2023 Ford F-350 Super Duty 4WD 2024 Ford F-250 Super Duty 4WD 2024 Ford F-350 Super Duty 4WD 2025 Ford F-250 Super Duty 4WD 2025 Ford F-350 Super Duty 4WD 2026 Ford F-250 Super Duty 4WD 2026 Ford F-350 Super Duty 4WD
