14-18 Ram 2500 Power Wagon (4WD - Coil/Coil) Suspension Lift Kit - Carli Suspension - CS-DPT25-14-PW

Pintop Leveling
CS-DPT25-14-PW
Required and Optional Parts to support this system:
Sway Bar Options (REQUIRED): CS-DSBD-14 or CS-DTSB3-1419
Radius Arms: CS-DFRA-14
Steering Stabilizer - High mount: CS-DHMSS-14
Steering Stabilizer - Low mount: CS-DLMSS-14
Ball Joints: CS-DBJP-14
Front Diff Guard: CS-DFDG-14
Levelling, mild lift, Dodge Ram
Carli Dodge Leveling Pintop 2.5 System, BASE
14-18 RAM POWERWAGON 2.0" LIFT PINTOP SYSTEM
Carli's most popular system, The pintop kit boasts Remote Reservoir King 2.5" shocks. Designed and tuned in house for the customer looking for substantial on and offroad performance improvement.
The Carli Pintop is a Jack-of-all-trades system that delivers a sedate yet confident on-road ride with all the harsh edges rounded and smoothed while making light- to medium-duty off-road escapades completely controlled and uneventful. The system features Carli-specific, blueprinted, King 2.5 shocks on all four corners. With a 2.5-inch diameter shock body these Pintop shocks delver 55% more piston surface area than a 2.0-inch shock. Carli engineers have designed a custom piston to produce proper base flow rates and optimize performance in robust ¾-ton and one-ton platforms. The Carli-spec shocks also feature shafts machined and polished from a solid piece of 17-4 stainless. The system delivers a dramatic increase is travel and the included adjustable track bar adds stability countering the sloppiness that can lead to Death Wobble. The truck will sit higher in the front for a level look and have more wheel travel thanks to the lighter rate Carli coil springs.
System includes multi rate front and rear coils, front and rear shock package, radius arm drop brackets, adjustable track bar, front and rear bump stop drops, rear sway bar end links and rear track bar drop.
Increases wheel travel to 9.3" front and 11" rear.
Allows for fitment of 37" tires.
Not compatible with factory rear air assist trucks.
Carli Pintop Leveling System, Base, 2” Lift, 14-18 Ram PowerWagon, Gas, R1 Coil
Parts Included: AS-DPT25SPKG-14-H; CS-DATB-1419; CS-DBLT-1419-R; CS-DEL-R-14; CS-DFBD-1; CS-DLRC-14-H; CS-DMRC-14-R1; CS-DPRBDROP-14-R; CS-DRAD-14; CS-DRBD-AL; CS-DRM-14-25
System includes multi rate front and rear coils, front and rear shock package, radius arm drop brackets, adjustable track bar, front and rear bump stop drops, rear sway bar end links and rear track bar drop.
Increases wheel travel to 9.3" front and 11" rear.
Allows for fitment of 37" tires.
Not compatible with factory rear air assist trucks.
California Proposition 65: WARNING: This product can expose you to chemicals including arsenic, which is known to the State of California to cause cancer. For more information, go to www.P65Warnings.ca.gov.

Detailed Fitment Results
Year Make Model Sub Model Drive Type 2014 Ram 2500 Power Wagon 4WD 2015 Ram 2500 Power Wagon 4WD 2016 Ram 2500 Power Wagon 4WD 2017 Ram 2500 Power Wagon 4WD 2018 Ram 2500 Power Wagon 4WD
