Long Travel Front Bypass Piggyback Shocks - King 3.50" Pair - Camburg - CAM-110175-2

Adding a front bypass shock to our Raptor long-travel kit adds a ton more control and bottoming resistance. This allows for a soft plush ride through the small stuff that doesn’t bottom out easily through the bigger hits and g-outs. Our Camburg spec custom King 3.5 bypass shocks have the proper tube layout valving and dimensions for maximum wheel travel and damping. We’ve spent extensive time developing these shocks for our kit. With the increased size and added oil capacity your shocks run cooler in extreme off-road use. You’re able to fine tune the shock by adjusting the compression and rebound adjusters to really dial in the ride based on how you’re driving. Maximum wheel travel; Improved response; Optimal handling
Self-Leveling: Yes
Active or Passive Suspension: Passive
Body Color: Silver
Shaft Material: Stainless Steel
Mounting Hardware Included: No
Mounting Hardware Included: Yes
Grade Type: Performance
Shock Absorber Rod End Measuring Point: Bottom
Shock Absorber Body End Measuring Point: Bottom
Boot Included: No
Body Diameter: 3.5 IN
Dust Shield Included: No
Bladder(s) Included: No
Bladder Heavy Duty Crimping Rings Included: No
Strut Mount Insulator(s) Included: No
Bladder Sleeve(s) Included: No
Coil Spring Insulator(s) Included: No
Includes Bump Stop: No
Body Material: Zinc Plated Steel
Compressed Length: 18.82 inch IN
Cylinder Finish: Coated
Dust Shield Diameter: Not Included
Extended Length: 26.76 inch IN
Hardware Included: No
Manufacturer: King
Prop 65 Y/N: No
Reservoir Type: Piggyback
Shock Diameter: 3.5 inch
Shock Type: King 3.5
Title: Camburg Engineering 2017-2020 Ford F-150 Raptor King Shock Absorber CAM-110175-2
Type: Performance

Detailed Fitment Results
Year Make Model Submodel 2017 Ford F-150 Raptor 2018 Ford F-150 Raptor 2019 Ford F-150 Raptor 2020 Ford F-150 Raptor
