Front Brake Caliper Tabs (12" Rotor x 3.5" Spacing) (970404) (pair) - Camburg - CAM-010069

These are the brake caliper tabs we use when building a Camburg rear end. These are designed for Wilwood’s 3.5? lug spacing. They also work with radial mount calipers with the proper machined adapters. These are CNC laser cut from thick 3/8? steel and are setup to be through bolted with a 7/16? bolt. These can be MIG or TIG welded. Select your axle housing tube size and the brake rotor diameter. Can be MIG or TIG welded; CNC Laser cut; 3/8" Steel
Mounting Hardware Included: No
Bolt size: 7/16 IN
Hardware Included: No
Housing Tube Size: 3.5 IN
Lug Spacing: 3.5 IN
Material: Steel
Position: Front
Prop 65 Y/N: No
Rotor Size: 12 IN
Thickness: 3/8 IN
Title: Camburg Engineering Front Brake Caliper Tabs (12 inch Rotor x 3.5 inch Spacing) (970404) (Pair) CAM-010069
