Out of Stock
AirdogSKU: BSD-ADP-R4SBC133
Diesel Lift Pump 100GPH Raptor RP-4G-100 2001-2010 Chevy Duramax - AirDog - R4SBC133
$696.96
Fitment Guide
16 matched applications
| Year | Make | Model | Submodel | Engine |
|---|---|---|---|---|
| 2002 | Chevrolet | Silverado 2500 HD | — | 6.6L DIESEL |
| 2004 | GMC | Sierra 3500 | — | 6.6L DIESEL |
| 2004 | GMC | Sierra 2500 HD | — | 6.6L DIESEL |
| 2004 | Chevrolet | Silverado 3500 | — | 6.6L DIESEL |
| 2001 | Chevrolet | Silverado 2500 HD | — | 6.6L DIESEL |
| 2001 | Chevrolet | Silverado 3500 | — | 6.6L DIESEL |
| 2001 | GMC | Sierra 2500 HD | — | 6.6L DIESEL |
| 2001 | GMC | Sierra 3500 | — | 6.6L DIESEL |
| 2002 | Chevrolet | Silverado 3500 | — | 6.6L DIESEL |
| 2002 | GMC | Sierra 2500 HD | — | 6.6L DIESEL |
| 2002 | GMC | Sierra 3500 | — | 6.6L DIESEL |
| 2003 | Chevrolet | Silverado 2500 HD | — | 6.6L DIESEL |
| 2003 | Chevrolet | Silverado 3500 | — | 6.6L DIESEL |
| 2003 | GMC | Sierra 2500 HD | — | 6.6L DIESEL |
| 2003 | GMC | Sierra 3500 | — | 6.6L DIESEL |
| 2004 | Chevrolet | Silverado 2500 HD | — | 6.6L DIESEL |
Shipping Estimate
Enter destination details for an instant shipping estimate. Final rates are confirmed at checkout.
Description
This is the Raptor-4G RP-100 fuel system for the 2001-2010 6.6L Duramax. This system mounts to the frame rail using the supplied sandwich plate mounting system.
The suction line connects to the factory suction fitting on top of the fuel module. The pressure side connects to the factory injection pump feed line on the frame back by the fuel cooler.
These pumps are internally regulated and do not require a return line. This is a 100GPH (Gallon Per Hour) fuel system for stock fuel trucks.
Check out our installation manual for a list of parts that are included with this kit.
Details:
Gallons per hour: 100GPH
Manufacturer: Duramax
Make: GM/Chevy
Liter: 6.6L
Engine Version: LB7
Engine Years: 2001-2004
Fuel Type: Diesel
The suction line connects to the factory suction fitting on top of the fuel module. The pressure side connects to the factory injection pump feed line on the frame back by the fuel cooler.
These pumps are internally regulated and do not require a return line. This is a 100GPH (Gallon Per Hour) fuel system for stock fuel trucks.
Check out our installation manual for a list of parts that are included with this kit.
Details:
Gallons per hour: 100GPH
Manufacturer: Duramax
Make: GM/Chevy
Liter: 6.6L
Engine Version: LB7
Engine Years: 2001-2004
Fuel Type: Diesel
